Connector 2 / 3 - OUT 1 / OUT 2 (Lemo 3 PIN)
(One Analogue and One Digital Output Each)
PIN
1
2
3
Chassis
User_Guide%3A_VBOX_IISX_Data_Logger/09_Technical_Properties_%E2%80%93_VBOX_IISX/PIN-OUTS%3A_VBOX_IISX
I/O
O
O
I
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
Function
Analogue Out 1 / 2
Digital Out 1 / 2
Ground
Ground
