Outputs: Digital Setup Menu (Channel 1 and 2)
OUTPUT
PULSES PER METER
MAX SPEED
MAX VALUE
MAX FREQUENCY
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
User_Guide%3A_VBOX_IISX_Data_Logger/03_Front_Panel_%E2%80%93_VBOX_IISX
Press '■' and then use the '◄' and '►' buttons to
associate either of the following channels SPEED, LAT
ACC and LONG ACC to the Digital output. Press '■' to
confirm.
This setting is only available when you have set the
output to SPEED.
Press '■' and use the '◄' and '►' buttons to set the
number of pulses per revolution. Press '■' to confirm
your selection.
Available range: 0.1 – 120 (in steps of 0.1)
This setting is only available when you have set the
output to SPEED.
Press ■' and use the '◄' and '►' buttons to set the
maximum Speed. Press '■' to confirm your selection.
Available range: 0 – 400 km/h (in steps of 1 km/h)
This setting is only available when you have set the
output to LAT ACC or LONG ACC.
Press '■' and use the '◄' and '►' buttons to set the
maximum value of that channel. Press '■' to confirm
your selection.
Available ranges:
0.5 – 2 g (in steps of 0.1 g) for LAT ACC
0.5 – 2 g (in steps of 0.1 g) for LONG ACC
This setting is only available when you have set the
output to LAT ACC or LONG ACC.
Press '■' and use the '◄' and '►' buttons to set the
maximum Frequency you want to use on the digital
output. Press '■' to confirm.
Available range: 1 – 50 kHz (in steps of 0.1 kHz)
