- Page 1 Front Bumper BXG.5200 (1)Contents: (2)Tools required: A. 18mm Wrench; B. 13mm Wrench; C. 19mm Socket Wrench; D. 18mm Socket Wrench; E. 14mm Socket Wrench; F. 5mm Hex Socket Wrench...
-
Page 2: Installation Instruction
(3)Installation time: About 2 hours, 2-3 persons needed. Installation time is different according to individual person （ ） (4)Installation instruction: Step 1: Remove the original front bumper and relative accessories. Step 2: Assemble the Part ”D”, “C2” and “C2”. - Page 3 Step 3: Install the Part ” A ” , “B1” and “B2” into the bumper.
- Page 4 Step 4: Install the Part ”R” onto the car frame using the factory nuts.
- Page 5 Notes: The Part “E” is used for the installation of the winch. If you have a need place a winch on the Part “R” and assemble it with Part “E”. Step 5: Install the bumper onto the pickup. Notes: Tighten up the bolts on both sides after adjusting the height of the bumper.
- Page 6 Step 6: Install the Part ”F” and “G” onto the bumper.
- Page 7 Step 7: The installation is complete. We hope you enjoy a wonderful off-road life with this quality product!
- Page 8 Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact us if you have any kind of question about your purchase. We will reply you in timely manner.
