- Page 1 Fender Flares BXG.2022 (1) Contents: (2) Tools required: a.13mm Wrench; b.13mm Socket Wrench; c.One Drill; d.11mm Drill bit; e.M8 Pneumatic Rivet Nut Setting...
- Page 2 About 2 hours, 1-2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.2022), please scan the QR code.
- Page 3 (4) Installation instruction: Step 1: Install the front part first.According to the fender flare’s bolt holes,then drill the 8 bolt holes. The figure shows the bolt holes which needed. Step 2: Tighten the front fender flare with PART”B”, PART”C” & PART”D”, by 13mm wrench &...
- Page 4 Step 3: After step 2,the front part finished. Step 4: Repeat the same method like “Step 1”. Step 5: Use the M8 Pneumatic Rivet Nut Setting Kit to install the PART”A”.
- Page 5 Step 6: Install the rear fender flare with PART”B”, PART”C” & PART”D”, by 13mm wrench & 13mm socket wrench. Step 7: Repeat all above steps for the driver side.
- Page 6 Step 8: Installation completed.
- Page 7 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
