- Page 1 Hooke Road Jeep Wrangler BXG.3009 JL 18-19 Tubular Half Doors (1) Contents: (2) Tools required: a. 5mm socket wrench; b. 14mm wrench;...
- Page 2 About 1.5 hours, 2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.3009), please scan the QR code.
- Page 3 (4) Installation instruction: Step 1: Begin by removing the factory doors.Then ready to assemble and install the half doors. Step 2: Assemble the part A,part C and part E.
- Page 4 Note:Don’t tighten screws above firmly for a adjustable assembly with the car frame. Step 3: Assemble the part B,part C ,part D and part F. Note:Don’t tighten screws above firmly for a adjustable assembly with the car frame. Step 4: Align the hinge and insert the front half door into the appropriate position slowly.
- Page 5 Then close the door slightly and screw the bolts.Don’t forget to tie the belt to the car frame.
- Page 6 Step 5: Align the hinge and insert the rear half door into the appropriate position slowly. Then close the door slightly and screw the bolts.Don’t forget to tie the belt to the car frame.
- Page 7 Step 6: Repeat the installation for the driver side.
- Page 8 Step 7: Once you have everything in place you are finished with the installation. Congratulations on the purchase and installation of a quality Hooke Road product!
- Page 9 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
