6.3.4 Retrieving SMS Text Messages from the ICX35-HWC

Using the ICX35-HWC AOI, SMS text messages that have been sent to the ICX35-
HWC from remote devices can be transferred into RSLogix 5000.
AT&T Users: For SMS texting functionality, you must power up the ICX35-HWC with
the SIM installed within 72 hours after AT&T activates the SIM card.
Security Tip: For increased security and to avoid spam, we recommend that you
restrict or limit the phone numbers allowed to send messages to the ICX35-HWC.
Please note that some cellular providers do not offer this capability.
Enter a '1' in the ICX35.CONTROL.Read_SMS controller tag and press
1
E
NTER
2 The ICX35.SMS.READ controller tag array populates with the date/time, time
zone, phone number, and SMS text information from the ICX35-HWC internal
buffer.
3 The ICX35.SMS.READ parameters are defined in the following table:
Controller Tag
ICX35.SMS.READ.Date_Time[0] – [1]
ICX35.SMS.READ.Date_Time[2] – [3]
ICX35.SMS.READ.Date_Time[4] – [5]
ICX35.SMS.READ.Date_Time[6] – [7]
ICX35.SMS.READ.Date_Time[8] – [9]
ICX35.SMS.READ.Date_Time[10] – [11]
ICX35.SMS.READ.Time_Zone
ICX35.SMS.READ.Phone_Number[0] – [23]
ICX35.SMS.READ.Message[0] – [159]
ProSoft Technology, Inc.
.
EtherNet/IP and SMS Text Messaging
Description
Year
Month
Day
Hour
Minute
Second
Time zone of ICX35-HWC present location
Phone number of SMS text origination.
(Ex. +18001112222)
Text message contents
