ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE
DF1 Full-Duplex
The DF1 Full-Duplex option displays the following additional parameters.
Parameter
Role
Timeout Bits
Port Type
DF1 Error Checking
The Master role contains the following additional fields:

Add Entry To Client Table List

Remove Selected Entries
If Slave is selected, the Encapsulation table is not visible.
You can add an entry to the Client Table list. Click on the A
T L button.
ABLE IST
The R
EMOVE
ProSoft Technology, Inc.
Description
Specifies the network role for the encapsulation process (Master, Slave).
Sets the length of time the gateway will wait when no further serial data is
received before encapsulating and transmitting data (0 to 65535).
Only TCP connections are supported for this protocol selection.
Specifies which type of error checking is used for DF1 data messages (BCC
or CRC).
S E button selects and removes entries from this list.
ELECTED NTRIES
ICX35-HWC Webpage
E T C
DD NTRY O LIENT
User Manual
