Arbor Technology EmCORE-i2702 Quick Installation Manual

3.5" miniboard
Hide thumbs Also See for EmCORE-i2702:

Advertisement

Quick Links

EmCORE-i2702
Form Factor
3.5" MiniBoard
VGA
Dual Channels 18-bit
LVDS/ Analog RGB/
TV-out
I/O
Mini-PCI/ SATA/ USB/
COM/ LPT
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
2011 All Rights Reserved.
®
All manuals and user guides at all-guides.com
CPU
Soldered onboard Intel®
Atom™ N270 1.6GHz
CPU
LAN
2 x Realtek 8111C PCIe
Gigabit Ethernet
- 1 -
3.5" Miniboard
Quick Installation Guide
Version 1.1
Chipset
Intel® 945GSE
Intel® ICH7M
Audio
Realtek ALC655 AC97
Audio Codec, Line-in/ Line-
out/ Mic-in
4041270200110P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EmCORE-i2702 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Arbor Technology EmCORE-i2702

  • Page 1 All manuals and user guides at all-guides.com EmCORE-i2702 3.5” Miniboard Quick Installation Guide Version 1.1 Form Factor Chipset 3.5” MiniBoard Soldered onboard Intel® Intel® 945GSE Atom™ N270 1.6GHz Intel® ICH7M Audio Dual Channels 18-bit 2 x Realtek 8111C PCIe Realtek ALC655 AC97...
