Figure 52. Supply fan performance with variable frequency drive - 60 ton cooling only air-cooled - direct drive
plenum, 80% width
8.0
7.5
2000 RPM
7.0
1900 RPM
6.5
6.0
1800 RPM
5.5
1700 RPM
5.0
1600 RPM
4.5
1500 RPM
4.0
1400 RPM
3.5
1300 RPM
3.0
1200 RPM
2.5
1100 RPM
2.0
1000 RPM
1.5
1.0
0.5
0.0
0 2500 5000
I I m m p p o o r r t t a a n n t t : : Maximum static pressure leaving the
rooftop is 4.0" H
pressure drops from the supply fan to the
space cannot exceed 4.0" H
RT-SVX072A-EN
2100 RPM 2200 RPM
7500 10000 12500 15000
Airflow, CFM
O positive. The static
2
O.
2
17500 20000 22500 25000
N N o o t t e e s s : :
• Shaded areas represent selectable area.
Contact your local Trane ® representative for
more information.
• 60 ton units with gas heat use the 30" DDP
fans. See
• Supply fan performance curve includes
internal resistance of rooftop. For total static
pressure determination, system external
static must be added to appropriate
component static pressure drops
(evaporator coil, filters, optional economizer,
optional relief fan, optional heating system,
optional cooling only extended casing,
optional roof curb).
• Maximum Cfm (for cULus approval) as
follows: 60 ton - 27,000 Cfm.
• Minimum motor horsepower is 10 hp (2 x 5
hp motors). Maximum motor horsepower is
40 hp (2 x 20 hp motors). Maximum fan RPM
is 2,200.
U U n n i i t t S S t t a a r r t t u u p p
27500 30000
Figure 58, p. 89 .
