P P r r e e - - I I n n s s t t a a l l l l a a t t i i o o n n
Unit Dimensions and Weight Information
Table 1. Unit dimensions and weight information
Description
Unit dimensions, 20–75 ton (SAH_)
Unit dimensions, 90–130 ton
Roof curb weights
Center-of-gravity illustration and related dimensional data

Factory Warranty Information

Compliance with the following is required to preserve
the factory warranty:

All Unit Installations

Startup MUST be performed by Trane, or an authorized
agent of Trane, to VALIDATE this WARRANTY.
Contractor must provide a two-week startup
notification and true start date to Trane (or an agent of
Trane specifically authorized to perform startup).
On all IntelliPak 1 units, a Trane factory startup is an
option and provides maximized unit reliability and
overall unit performance in addition to preserving the
standard factory warranty.

Additional Requirements for Units

Requiring Disassembly

When a new fully assembled IntelliPak is shipped and
received from our Trane manufacturing location, and,
for any reason, it requires disassembly or partial
disassembly, which could include but is not limited to
the evaporator, condenser, control panel, compressor/
motor, factory mounted starter, or any other
components originally attached to the fully assembled
unit, compliance with the following is required to
preserve the factory warranty:
14
Air-Cooled Condenser
Figure 1, p. 18, Figure 2, p.
Figure 5, p. 23
Figure 6, p. 24
• Trane, or an agent of Trane specifically authorized
to perform start-up and warranty of Trane®
products, will perform or have direct on-site
technical supervision of the disassembly and
reassembly work.
• The installing contractor must notify Trane, or an
agent of Trane specifically authorized to perform
start-up and warranty of Trane® products, two
weeks in advance of the scheduled disassembly
work to coordinate the disassembly and
reassembly work.
• Start-up must be performed by Trane or an agent of
Trane specifically authorized to perform start-up
and warranty of Trane® products.
Trane, or an agent of Trane specifically authorized to
perform startup and warranty of Trane® products, will
provide qualified personnel and standard hand tools to
perform the disassembly work at a location specified
by the contractor. The contractor shall provide the
rigging equipment, such as chain falls, gantries, cranes,
forklifts, etc., necessary for the disassembly and
reassembly work and the required qualified personnel
to operate the necessary rigging equipment. See
"Warranty and Liability Clause," p. 160
details.
Reference
19, Figure 3, p. 20, Figure 4, p. 21
for additional
RT-SVX072A-EN
