User Guide
HUMAN MEASUREMENT
against the R side of the electrode board, and the left wrist is
against the L side of the electrode board.
Figure 51. Wrist Strap Placement Diagram
Figure 52. Electrode Board Placement
analog.com
EVAL-ADPD6000
Figure 53. ECG Measurement Waveform
BIA MEASUREMENT
For BIA measurement, place the electrode board against the wrist
in the same way as shown for ECG measurement (see
52). Run VSM Client to display the BIA measurement results (see
Figure 54
for an example). BIOZ amplitude is the body impedance
of the user.
Figure 54. BIA Measurement Results
Figure
Rev. 0 | 14 of 20
