2.1.1. Power supply requirements
A single external power supply is necessary to operate HPT435. The external power supply needs
to be Listed for US and Certified for EU countries, it needs also to be a Limited Power Source and
rated for Outdoor Use and have an output rated for +12V, 10A. This may not be the same range as
other JAVAD GNSS products with which you are familiar.
C : To avoid the introduction of hazards when operating and installing, before connecting of the
AUTION
equipment to the supply, make sure that the supply meets local and national safety ordi-
nances and matches the equipment's voltage and current requirements.
C : Never attempt any maintenance or cleaning of the supply while plugged in. Always remove
AUTION
supply from AC power before attempting service or cleaning.
Warning: If the voltage supplied is below the minimum specification, the modem will suspend operation. If the
voltage supplied is above the maximum specification, the modem may be permanently damaged,
voiding your warranty.
Make sure cords are located so that will not be stepped on, tripped over, or otherwise
subjected to damage or stress. Do not operate equipment with a damaged cord or plug –
replace immediately. To reduce the risk of damage to the equipment, pull by the plug body
rather than the output cord when disconnecting the equipment.
Do not operate the supply if it has received a sharp blow, been dropped, or otherwise
damaged. Do not disassemble the supply.
Warning: Before connecting the external power source and the modem, make sure that the power source
matches the modem's voltage and current requirements.
