A.1.3. Transmitter Specifications
Table A-3 lists the transmitter specifications.
Parameter
Output Power
Output Power Control Accuracy
Carrier Frequency Stability
Max. Frequency Error
Adjacent Channel Power (Conducted)
25/12.5/6.25 kHz CS
Spurious Emission (Conducted)
Spurious Emission (Radiated)
A.1.4. Receiver Specifications
Table A-4 lists the receiver specifications.
Parameter
Noise Figure
Receiver Sensitivity
BER 1x10-4, 25 kHz CS
Dynamic Range
Max. Input Signal Level
Co-channel Rejection
Adjacent Channel Selectivity
www.javad.com
Table A-3. Transmitter Specifications
USA 25 dBm to 45.44 dB m in 1 dB steps (320 mW to 35W)
EU 25 dBm to 41.76 dBm in 1 dB steps (320 mW to 15W)
±1.5 dB (at normal test conditions)
±1.5 ppm initial stability over temp with ±3.0 ppm aging/year
±1.0 kHz (at normal test conditions)
±1.5 kHz (under extreme test conditions)
USA, Canada Part §90.210 (C, D, E)
EU Clause 4.2.4 EN 300 113-2 (60 dBc)
-36 dBm (9 kHz – 1GHz)
-30 dBm (1GHz – 4 GHz)
-36 dBm (9 kHz to 1 GHz)
-30 dBm (1 GHz to 4 GHz)
Table A-4. Receiver Specifications
4 dB
DBPSK -116 dBm 25kHz / -117 dBm 12.5kHz
DQPSK -115 dBm 25kHz / -116 dBm 12.5kHz
D8PSK -110 dBm 25kHz / -111 dBm 12.5kHz
D16QAM -106 dBm 25kHz / -107 dBm 12.5kHz
GMSK -113 dBm 25kHz / -114 dBm 12.5kHz
-115 to –15 dBm
-10 dBm
-8 dB for 25 kHz Channel Spacing
-12 dB for 12.5 kHz Channel Spacing
-16 dB for 6.25 kHz Channel Spacing
70 dB for 25 kHz Channel Spacing
60 dB for 12.5 kHz Channel Spacing
50 dB for 6.25 kHz Channel Spacing
Specifications
HPT435 UHF Modem Specifications

Transmitter Specifications

Specification
Specification
