- Page 1 ® XTENDEX Series ST-C6USB4K18GB-230T 4K 18Gbps HDMI USB KVM Extender via One CAT6/6a/7 Cable Installation and Operation Manual ST-C6USB4K18GB-230T Local and Remote MAN427 Rev Date 11/14/2022...
- Page 2 TRADEMARK XTENDEX and the NTI logo are registered trademarks of Network Technologies Inc in the U.S. and other countries. All other brand names and trademarks or registered trademarks are the property of their respective owners. COPYRIGHT Copyright © 2022 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials Included ................................2 Features and Functions..............................3 Installation ..................................5 Connect the Transmitter .............................. 5 Connect the Receiver ..............................6 Technical Specifications..............................7 Interconnection Cable Wiring Method ..........................8 Troubleshooting................................8 Warranty Information............................... 9... -
Page 4: Introduction
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender INTRODUCTION The XTENDEX® 4K 18Gbps HDMI USB KVM Extender via One CAT6/6a/7 Cable provides remote KVM (USB keyboard, USB mouse, and 4Kx2K 60Hz UHD HDMI monitor) access to a USB computer up to 230 feet (70 m) away via CAT6/6a/7 cable. -
Page 5: Materials Included
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender MATERIALS INCLUDED Materials supplied with this kit 1 pc Transmitter (Local Unit) 1 pc Receiver (Remote Unit) 1 pc 110-240VAC, 50 or 60Hz-5VDC/2A AC Adapter with US Plug (For the Local Unit) ... -
Page 6: Features And Functions
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender FEATURES AND FUNCTIONS LABEL CONNECTOR/LED DESCRIPTION DC 5V-12V 2.1x5.5mm Power For connection of power supply Jack HDMI OUTPUT HDMI Female Connect a local HDMI display device HDMI INPUT HDMI Female Connect video source device... - Page 7 NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender LABEL CONNECTOR/LED DESCRIPTION DC 5V-12V 2.1x5.5mm Power For connection of power supply Jack Optical Audio Connect a set of digital audio speakers S/PDIF OUT Female HDMI Female Connect a local HDMI display device...
-
Page 8: Installation
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender INSTALLATION Connect the Transmitter 1. Connect the source device to the "HDMI INPUT" port of the Transmitter with an HDMI cable. 2. Connect a USB Type A male to USB Type A male cable (supplied) between the source and the USB Type A female port on the Transmitter. -
Page 9: Connect The Receiver
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender Connect the Receiver 1.Connect the "HDMI OUTPUT" port of the receiver to the display device with another HDMI cable. 2. If the display device is a touchscreen monitor, connect a USB cable from it to one of the USB Type A ports labeled "KVM". -
Page 10: Technical Specifications
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender TECHNICAL SPECIFICATIONS Transmitter (Local Unit) Compatible with a USB computer with Ultra-HD HDMI output. Multiplatform support: Windows 7/10/11, Linux, and MAC OS 10/12. One female HDMI connector for source. ... -
Page 11: Interconnection Cable Wiring Method
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender INTERCONNECTION CABLE WIRING METHOD The connection cable between the remote and local is terminated with RJ45 connectors and must be wired according to the EIA/TIA 568B industry standard. Wiring is as per the table and drawing below. -
Page 12: Warranty Information
NTI XTENDEX 4K60Hz 70m Point-to-Point HDMI Extender WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com...
