- Page 1 ® XTENDEX Series ST-C6USB4K18GB-HDBT230 4K 18Gbps HDMI USB KVM Extender over HDBaseT Installation and Operation Manual MAN341 Rev Date 12/10/2019...
- Page 2 Note: CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................1 Preparation for Installation .............................. 2 Features and Functions..............................3 Installation ..................................4 IR Connection ................................6 Troubleshooting................................7 Interconnection Cable Wiring Method ..........................7 Technical Specifications..............................8 Warranty Information............................... 9... -
Page 4: Introduction
CAT5/5e cable is NOT recommended for use with this product. WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will... -
Page 5: Preparation For Installation
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will... -
Page 6: Features And Functions
NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE FEATURES AND FUNCTIONS Label Description DC 12V For optional connection of power supply Power Illuminates when the Local Unit is powered ON Arrow Illuminates when there is data transmission from the Receiver; Flashes when there is no... -
Page 7: Installation
NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE INSTALLATION Note: The video source and display device can be powered-ON at any point during this installation. 1. Connect a video source to the HDMI port on the Local Unit using one of the cables recommended in the chart on page 1. - Page 8 NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE 3. Connect a CAT6/6a/7 cable (up to 230 feet in length) between the "HDBT In" port on the Remote Unit and the "HDBT Out" port on the Local Unit. 4. Connect AC Adapter to the "DC 12V" port on the Remote Unit.
-
Page 9: Ir Connection
NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE IR Connection The ST-C6USB4K18GB-HDBT230 supports Bi-directional IR pass back. A user can control devices at each end of the installation. With an IR Emitter and IR Receiver connected at each end, a user can control a TV connected at the Remote Unit and the DVD player connected to the Local Unit. -
Page 10: Troubleshooting
WARNING: The CATx connection cable used between the NTI XTENDEX Series Local Unit and Remote Unit or any XTENDEX Series products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER... -
Page 11: Technical Specifications
NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE TECHNICAL SPECIFICATIONS Items Specifications Local Unit USB Computer or HDTV Video Source with HDMI output Compatibility Platforms supported Multiplatform support: Windows 2000/XP/Vista/7/8/10, Windows Server 2000/2003/2008/2012/2016, Solaris, Linux, FreeBSD, and MAC OS 9/10. -
Page 12: Warranty Information
NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com...
