  • Page 1 SDS-E Series Smart Digital Storage Oscilloscopes User Manual Note: "V" is for VGA port (optional) WWW.OWON.COM.CN...
  • Page 2 Lilliput Company. Fujian Lilliput Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: www.owon.com.cn E-mail: info@owon.com.cn...
  • Page 3 Please contact the nearest Lilliput's Sales and Service Offices for services or a complete copy of the warranty statement. For better after-sales service, please visit www.owon.com.cn and register the purchased product online. Excepting the after-sales services provided in this summary or the applicable warranty...

  • Page 4: Table Of Contents

    Table of contents 1. General Safety Requirements ..................1 2. Safety Terms and Symbols ....................2 3. General Characteristics ....................4 4. Junior User Guidebook ....................5 Introduction to the Structure of the Oscilloscope ..............6 Front Panel ............................... 6 Right Side Panel ............................
  • Page 5 How to Implement the Auxiliary System Function Setting ..............63 How to Measure Automatically......................68 How to Measure with Cursors ........................ 72 How to Use Autoscale ..........................77 How to Use Built-in Help ........................78 How to Use Executive Buttons....................... 79 6.

  • Page 6: General Safety Requirements

    1.General Safety Requirements 1. General Safety Requirements Before any operations, please read the following safety precautions to avoid any possible bodily injury and prevent this product or any other products connected from damage. In order to avoid any contingent danger, this product is only used within the range specified.

  • Page 7: Safety Terms And Symbols

    2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property.
  • Page 8 2.Safety Terms and Symbols To avoid body damage and prevent product and connected equipment damage, carefully read the following safety information before using the test tool. This product can only be used in the specified applications. Warning The two channels of the oscilloscope are non-isolated electrically. The channels should adopt common basis during measuring.

  • Page 9: General Characteristics

    3.General Characteristics 3. General Characteristics  Bandwidth: 30 MHz – 125 MHz;  Sample rate: 500 MS/s - 1 GS/s;  1 M record length (10 M optional); (10 K for SDS5032E(V), SDS5052E(V))  8 inch high def TFT display; ...

  • Page 10: Junior User Guidebook

    4.Junior User Guidebook 4. Junior User Guidebook This chapter deals with the following topics mainly:  Introduction to the structure of the oscilloscope  Introduction to the user interface  How to implement the general inspection  How to implement the function inspection ...

  • Page 11: Introduction To The Structure Of The Oscilloscope

    4.Junior User Guidebook Introduction to the Structure of the Oscilloscope When you get a new-type oscilloscope, you should get acquainted with its front panel at first and the digital storage oscilloscope is no exception. This chapter makes a simple description of the operation and function of the front panel of the oscilloscope, enabling you to be familiar with the use of the oscilloscope in the shortest time.

  • Page 12: Right Side Panel

    4.Junior User Guidebook Right Side Panel Figure 4-2 Right side panel 1. USB Host port: It is used to transfer data when external USB equipment connects to the oscilloscope regarded as "host device". For example: use this port to save waveform file into USB flash disk.

  • Page 13: Rear Panel

    4.Junior User Guidebook Rear Panel Figure 4-3 Rear Panel 1. Handle 2. Air vents 3. AC power input jack 4. Fuse 5. Foot stool (which can adjust the tilt angle of the oscilloscope)

  • Page 14: Control (Key And Knob) Area

    4.Junior User Guidebook Control (key and knob) Area Figure 4-4 Keys Overview 1. Menu option setting: H1 - H5 2. Menu option setting: F1 - F5 3. Menu off：turn off the menu ○ 4. M knob (Multipurpose knob): when a M symbol appears in the menu, it indicates you can turn the M knob to select the menu or set the value.

  • Page 15: User Interface Introduction

    4.Junior User Guidebook User Interface Introduction Figure 4-5 Illustrative Drawing of Display Interfaces (SDS5032E(V) shown) Waveform Display Area. The state of trigger, including: Auto: Automatic mode and acquire waveform without triggering. Trig: Trigger detected and acquire waveform. Ready: Pre-triggered data captured and ready for a trigger. Scan: Capture and display the waveform continuously.
  • Page 16 4.Junior User Guidebook 13. The frequency of the trigger signal of CH1. 14. It indicates the current function menu. 15. Current trigger type: Rising edge triggering Falling edge triggering Video line synchronous triggering Video field synchronous triggering The reading shows the trigger level value of the corresponding channel. 16.

  • Page 17: How To Implement The General Inspection

    4.Junior User Guidebook How to Implement the General Inspection After you get a new oscilloscope, it is recommended that you should make a check on the instrument according to the following steps: 1. Check whether there is any damage caused by transportation. If it is found that the packaging carton or the foamed plastic protection cushion has suffered serious damage, do not throw it away first till the complete device and its accessories succeed in the electrical and mechanical property tests.

  • Page 18: How To Implement The Probe Compensation

    4.Junior User Guidebook Connect the probe tip and the ground clamp to the connector of the probe compensator. 3. Press the "Autoset" Button. The square wave of 1 KHz frequency and 5V peak-peak value will be displayed in several seconds (see Figure 4-6). Figure 4-6 Auto set Check CH2 by repeating Step 2 and Step 3.

  • Page 19: How To Set The Probe Attenuation Coefficient

    4.Junior User Guidebook Overcompensated Compensated correctly Under compensated Figure 4-7 Displayed Waveforms of the Probe Compensation 3. Repeat the steps mentioned if needed. Figure 4-8 Adjust Probe How to Set the Probe Attenuation Coefficient The probe has several attenuation coefficients, which will influence the vertical scale factor of the oscilloscope.

  • Page 20: How To Use The Probe Safely

    4.Junior User Guidebook Figure 4-9 Attenuation Switch Caution: When the attenuation switch is set to 1X, the probe will limit the bandwidth of the oscilloscope in 5MHz. To use the full bandwidth of the oscilloscope, the switch must be set to 10X. How to Use the Probe Safely The safety guard ring around the probe body protects your finger against any electric shock, shown as Figure 4-10.

  • Page 21: Introduction To The Vertical System

    4.Junior User Guidebook Cal"; run the program after everything is ready. Introduction to the Vertical System As shown in Figure 4-11, there are a few of buttons and knobs in VERTICAL CONTROLS. The following practices will gradually direct you to be familiar with the using of the vertical setting.

  • Page 22: Introduction To The Horizontal System

    4.Junior User Guidebook menu, symbols, waveforms and scale factor status information of the corresponding channel will be displayed in the screen. Introduction to the Horizontal System Shown as Figure 4-12, there are a button and two knobs in the "HORIZONTAL CONTROLS".
  • Page 23 4.Junior User Guidebook Figure 4-13 Trigger Control Zone Press the "Trigger Menu" button and call out the trigger menu. With the operations of the menu selection buttons, the trigger setting can be changed. 2. Use the "TRIG LEVEL" knob to change the trigger level setting. By rotating the "TRIG LEVEL"...

  • Page 24: Advanced User Guidebook

    5.Advanced User Guidebook 5. Advanced User Guidebook Up till now, you have already been familiar with the basic operations of the function areas, buttons and knobs in the front panel of the oscilloscope. Based the introduction of the previous Chapter, the user should have an initial knowledge of the determination of the change of the oscilloscope setting through observing the status bar.

  • Page 25: How To Set The Vertical System

    5.Advanced User Guidebook How to Set the Vertical System The VERTICAL CONTROLS includes three menu buttons such as CH1 MENU, CH2 MENU and Math, and four knobs such as VERTICAL POSITION, VOLTS/DIV for each channel. Setting of CH1 and CH2 Each channel has an independent vertical menu and each item is set respectively based on the channel.
  • Page 26 5.Advanced User Guidebook The description of the Channel Menu is shown as the following list: Function Description Setting Menu Pass both AC and DC components of the input signal. Coupling Block the DC component of the input signal. GROUND Disconnect the input signal. Display inverted waveform.
  • Page 27 5.Advanced User Guidebook Figure 5-2 AC Coupling Oscillogram 2. To adjust the probe attenuation For correct measurements, the attenuation coefficient settings in the operating menu of the Channel should always match what is on the probe (see "How to Set the Probe Attenuation Coefficient"...
  • Page 28 5.Advanced User Guidebook Figure 5-3 Regulation of the Attenuation Ratio of the Probe A list of the probe attenuation coefficient and the corresponding menu settings: Attenuation Coefficient of the Probe Corresponding Menu Setting 10:1 100:1 X100 1000:1 X1000 3. To measure current by probing the voltage drop across a resistor Take the Channel 1 as an example, if you are measuring current by probing the voltage drop across a 1Ω...
  • Page 29 5.Advanced User Guidebook Figure 5-4 Measure Current 4. To invert a waveform Waveform inverted: the displayed signal is turned 180 degrees against the phase of the earth potential. Taking the Channel 1 for example, the operation steps are shown as follows: (1) Press the CH1 MENU button to show the CH1 SETUP menu.
  • Page 30 5.Advanced User Guidebook Figure 5-5 Original Waveform Figure 5-6 Inverted Waveform To set bandwidth limit (Only SDS7102E(V) and SDS7122E(V) have this function) When high frequency components of a waveform are not important to its analysis, the bandwidth limit control can be used to reject frequencies above 20 MHz. Taking the Channel 1 for example, the operation steps are shown as below: (1) Press the CH1 MENU button to show CH1 SETUP menu.

  • Page 31: Use Mathematical Manipulation Function

    5.Advanced User Guidebook (3) Press the F1 button to select the Band Limit as full band. The high frequency of the signal will be allowed to pass. (4) Press the F2 button to select the Band Limit as 20M. The bandwidth is limited to 20 MHz.
  • Page 32 5.Advanced User Guidebook Rectangle Blackman Hanning Select dB for Format. Format Vrms Select Vrms for Format. ×1 Set multiple ×1. ×2 Set multiple ×2. Zoom ×5 Set multiple ×5. ×10 Set multiple ×10. Taking the additive operation between Channel 1 and Channels 2 for example, the operation steps are as follows: 1.

  • Page 33: Using Fft Function

    5.Advanced User Guidebook Figure 5-8 Waveform resulted from CH1 +CH2 Using FFT function The FFT (fast Fourier transform) math function mathematically converts a time-domain waveform into its frequency components. It is very useful for analyzing the input signal on Oscilloscope. You can match these frequencies with known system frequencies, such as system clocks, oscillators, or power supplies.
  • Page 34 5.Advanced User Guidebook Better solution for magnitude than Rectangle, and good for frequency as well. It has slightly better frequency resolution than Hanning. Recommend to use for: Hamming  Sine, periodic and narrow band random noise.  Transients or bursts where the signal levels before and after the event are significantly different.
  • Page 35 5.Advanced User Guidebook Figure 5-9 Hamming window Figure 5-10 Rectangle window...
  • Page 36 5.Advanced User Guidebook Figure 5-11 Blackman window Figure 5-12 Hanning window Notes for using FFT  Use Zoom function to magnify the FFT waveform if necessary.  Use the default dB scale for details of multiple frequencies, even if they have very different amplitudes.

  • Page 37: Use Vertical Position And Volts/Div Knobs

    5.Advanced User Guidebook What is Nyquist frequency? The Nyquist frequency is the highest frequency that any real-time digitizing oscilloscope can acquire without aliasing. This frequency is half of the sample rate. Frequencies above the Nyquist frequency will be under sampled, which causes aliasing. So pay more attention to the relation between the frequency being sampled and measured.

  • Page 38: How To Set The Horizontal System

    5.Advanced User Guidebook How to Set the Horizontal System The HORIZONTAL CONTROLS includes the HORIZ MENU button and such knobs as HORIZONTAL POSITION and SEC/DIV. 1. HORIZONTAL POSITION knob: this knob is used to adjust the horizontal positions of all channels (include those obtained from the mathematical manipulation), the analytic resolution of which changes with the time base.
  • Page 39 5.Advanced User Guidebook Figure 5-15 Main Time Base Set Window Press the H2 menu selection button and choose Set. The screen will show a window area defined by two cursors. Use the HORIZONTAL POSITION and SEC/DIV knobs to adjust the horizontal position and size of this window area. In FFT mode, Set menu is invalid.

  • Page 40: How To Set The Trigger System

    5.Advanced User Guidebook Figure 5-17 Zoom Window How to Set the Trigger System Trigger determines when DSO starts to acquire data and display waveform. Once trigger is set correctly, it can convert the unstable display to meaningful waveform. When DSO starts to acquire data, it will collect enough data to draw waveform on left of trigger point.
  • Page 41 5.Advanced User Guidebook Edge Trigger: It occurs when the trigger input passes through a specified voltage level with the specified slope. Video Trigger: Trigger on fields or lines for standard video signal. Slope Trigger: The oscilloscope begins to trigger according to the signal rising or falling speed.
  • Page 42 5.Advanced User Guidebook Holdoff 100 ns – 10 s, turn the M knob to set time interval before another trigger occur. Reset Set Holdoff time as default value (100 ns). 2. Video Trigger Choose video trigger to trigger on fields or lines of NTSC, PAL or SECAM standard video signals.
  • Page 43 5.Advanced User Guidebook Single Slope Set vertical channel trigger type as slope trigger. Mode Select CH1 as the trigger source. Source Select CH2 as the trigger source. slope Slope selecting When Set slope condition; turn the M knob to set slope time.

  • Page 44: Alternate Trigger

    5.Advanced User Guidebook Select pulse width condition and adjust the M knob to set time. Auto Acquire waveform even no trigger occurred Normal Acquire waveform when trigger occurred Mode Single When trigger occurs, acquire one waveform then stop Holdoff 100 ns - 10 s, adjust M knob to set time interval Holdoff before another trigger occur.
  • Page 45 5.Advanced User Guidebook Trigger in signal rising edge Slope Trigger in signal falling edge Auto Acquire waveform even no trigger occurred Mode Holdoff 100 ns - 10 s, adjust M knob to set time interval before another trigger occur. Holdoff Reset Set Holdoff time as 100 ns 2.
  • Page 46 5.Advanced User Guidebook slope Select slope condition When Set slope condition; turn the M knob to set time. Turn the M knob to set the High level High level Turn the M knob to set Threshold Low level Low level Slew rate=( Slew rate High level- Low level)/ Settings...

  • Page 47: How To Operate The Function Menu

    5.Advanced User Guidebook Term interpretation 1. Source: Trigger can occur from several sources: Input channels (CH1, CH2), Ext, Ext/5.  Input: It is the most commonly used trigger source. The channel will work when selected as a trigger source whatever displayed or not. ...

  • Page 48: How To Implement Sampling Setup

    5.Advanced User Guidebook How to Implement Sampling Setup Press the Acquire button and the menu is displayed in the screen, shown as Figure 5-26. Figure 5-26 ACQU MODE Menu The description of the Acqu Mode Menu is shown as follows: Function Menu Setting Description...
  • Page 49 5.Advanced User Guidebook Figure 5-27 Peak Detect mode, under which the burrs on the falling edge of the square wave, can be detected and the noise is heavy. Figure 5-28 Normal ACQU Mode display, in which no burr can be detected.

  • Page 50: How To Set The Display System

    5.Advanced User Guidebook Figure 5-29 The displayed waveform after the noise is removed under the Average Mode, in which the average number of 16 is set. How to Set the Display System Press the Display button and the menu displayed in the screen is shown as Figure 5-30. Figure 5-30 Display Set Menu The description of the Display Set Menu is shown as follows: Function Menu...
  • Page 51 5.Advanced User Guidebook Vect and Dots types. The differences between the two display types can be observed through the comparison between Figure 5-31 and Figure 5-32. Figure 5-31 Display in the Vector Form Figure 5-32 Display in Dots form Persist When the Persist function is used, the persistence display effect of the picture tube oscilloscope can be simulated.
  • Page 52 5.Advanced User Guidebook pressing the F2 button, the persistence will be cleared. Figure 5-33 Infinite Persistence Display XY Format This format is only applicable to Channel 1 and Channel 2. After the XY display format is selected, Channel 1 is displayed in the horizontal axis and Channel 2 in the vertical axis; the oscilloscope is set in the un-triggered sample mode: the data are displayed as bright spots.

  • Page 53: How To Save And Recall A Waveform

    5.Advanced User Guidebook Figure 5-34 XY Display Mode Trig Freq It is a 6-digit trig freq. The trig freq can measure frequencies from 2Hz to the full bandwidth. Only if the measured channel has triggering signal and in Edge mode, it can measure frequency correctly.
  • Page 54 (see " " on P43); Record Length Menu External the file name is editable. The waveform file could be open by OWON waveform analysis software (on the supplied CD). When the type is Setting, the menu shows as following: Setting1….. Setting8...
  • Page 55 5.Advanced User Guidebook Load Recall the setting from the selected address When the type is Image, the menu shows as following: Save the current display screen. The file can be only stored in a USB storage, so a USB Save storage must be connected first.
  • Page 56 5.Advanced User Guidebook Whatever the Type of save menu is set, you can save the waveform by just pressing the Copy panel button in any user interface. If the Storage of the save menu is set as "External", you should install the USB disk. Please refer to the contents below to install the USB disk and name the file to be saved.
  • Page 57 5.Advanced User Guidebook second method – using the formatting tools.) Use system-provided function to format the USB disk 1. Connect the USB disk to the computer. 2. Right click Computer- Manage to enter Computer Management interface. 3. Click Disk Management menu, and information about the USB disk will display on the right side with red mark 1 and 2.
  • Page 58 5.Advanced User Guidebook Figure 5-40: Formatting the USB disk setting 6. Formatting process. Figure 5-41: Formatting the USB disk Check whether the USB disk is FAT32 with allocation unit size 4096 after formatting. Use Minitool Partition Wizard to format Download URL: http://www.partitionwizard.com/free-partition-manager.html Tip: There are many tools for the USB disk formatting on the market, just take Minitool Partition Wizard for example here.
  • Page 59 5.Advanced User Guidebook Figure 5-42: Reload Disk 4. Right click 1 or 2 red mark area, choose Format. Figure 5-43: Choose format 5. Set File System FAT32, Cluster size 4096. Click OK. Figure 5-44: Format setting 6. Click Apply at the top left of the menu. Then click Yes on the pop-up warning to begin formatting.

  • Page 60: How To Cut And Recall A Waveform

    To cut waveform between two time cursors, generate a file with the suffix “*.ota”, and save it to external memory device. To recall the waveform is to use AG1022F or AG2052F manufactured by OWON to read *.ota and recall the waveform being cut from oscilloscope.
  • Page 61 5.Advanced User Guidebook 3. Press the H1 button, the type menu will display at the left of the screen, turn the M knob to choose Cut Wave for type. Move cursor1 (CH1 zero position knob) and cursor2 (CH2 zero position knob) to choose the range of wave to be cut.

  • Page 62: How To Record/Playback Waveforms

    5.Advanced User Guidebook Figure 5-50: choose the .ota file (3) Choose Recall output. And the tip “Read file successfully” will show on the interface. Figure 5-51: Read file Tips: 1. Normally the frequency, amplitude, and offset of the recalled wave are the same as the wave being cut, but when the frequency, amplitude, and offset are set out of the limit range, then AG generators would use the current parameter, which leads to the recalled wave not totally the same as the cut wave.
  • Page 63 5.Advanced User Guidebook contains two kinds: Internal and External. When the storage medium is Internal, Wave Record contains four modes: OFF, Record, Playback and Storage. When storage medium is External（See P61 Wave Record Menu of External Storage）, Wave Record contains two modes: OFF, Record. Record: To record wave according to the interval until it reaches the end frame set.
  • Page 64 5.Advanced User Guidebook Start frame Turn the M knob to select the number of start frame to playback (1 - 1000) End frame Turn the M knob to select the number of end frame Playback Mode to playback (1 - 1000) FrameSet Cur frame Turn the M knob to select the number of current...
  • Page 65 5.Advanced User Guidebook Figure 5-54 Wave Storage To use wave record function, do as follows: (1) Press Save button. (2) Press H1 button, turn the M knob to choose Record. (3) Press H2 button. In the Mode menu, press F2 button to choose Record. (4) Press H3 button.
  • Page 66 5.Advanced User Guidebook Figure 5-55: Wave Record Menu of External Storage Record menu (External Storage) shows as follows: Menu Setting Instruction Close wave record function Mode Record Set record menu End frame Turn the M knob to select the number of frames to record (1 - 1000) Record mode Turn the M knob to select the interval between...
  • Page 67 5.Advanced User Guidebook Figure 5-56: Frame setting (External Storage) To use wave record to external, do as follows: 1. Press Save button. 2. Press H1 button, turn the M knob to choose Record. 3. Press H2 button. In the Mode menu, press F2 button to choose Record. Press H3 to choose External as the storage medium.

  • Page 68: How To Implement The Auxiliary System Function Setting

    5.Advanced User Guidebook Figure 5-57: Play back waveform by software How to Implement the Auxiliary System Function Setting ●Config Press the Utility button and turn the M knob to select Config to go to the following menu. Figure 5-58 Configuration Menu The description of Configuration Menu is shown as the follows: Function Menu Setting...
  • Page 69 5.Advanced User Guidebook menu. Figure 5-59 Display Menu The description of Display Menu is shown as the follows: Function Menu Setting Description BackLight 0% - 100% Turn the M knob to adjust the backlight. Graticule Select the grid type Menu Time 5 s - 50 s, OFF Set the disappear time of menu ●Adjust Press the Utility button and turn the M knob to select the Adjust to go to the following...
  • Page 70 5.Advanced User Guidebook Figure 5-61 Self-Calibration Probe checking: To check whether probe attenuation is good. The results contain 3 circumstances: Overflow compensation, Good compensation, Inadequate compensation. According to the checking result, users can adjust probe attenuation to the best. Operation steps are as follows: 1.
  • Page 71 5.Advanced User Guidebook ● Pass/Fail The Pass/Fail function monitors changes of signals and output pass or fail signals by comparing the input signal that is within the pre-defined mask. Press the Utility button and turn the M knob to select the Pass/fail to go to the following menu.
  • Page 72 5.Advanced User Guidebook 6. Save rule: Press H5 button, then F2 button to save the rules, which could be called up at once when need, press F3 button to call up the rule saved. Figure 5-64 Pass/Fail test Note: 1. When Pass/Fail is ON, if XY or FFT is ready to run, then Pass/Fail will be closed; under the mode of XY or FFT, Pass/Fail is unable.

  • Page 73: How To Measure Automatically

    5.Advanced User Guidebook ● LAN Set Using the LAN port, the oscilloscope can be connected with a computer directly, or through the router to connect. The network parameters can be set in the menu below. Refer to "Using LAN Port" on P82 for the operation steps. Press the Utility button and turn the M knob to select the LAN Set to go to the following menu.
  • Page 74 5.Advanced User Guidebook Figure 5-67 Measure Menu The "Automatic Measurements" menu is described as the following table: Function Menu Setting Description Type Press F1 ,show the measure types Source Select the source Show all Show all the measures on the screen Add the selected measure types (shown at the left bottom, you could only add 8 types at most)
  • Page 75 5.Advanced User Guidebook 6. Press the F1 button again, the type items will display at the left of screen, and turn the M knob to choose Freq. 7. Press the F4 button, the frequency added completes, finish setting of CH1. 8.
  • Page 76 5.Advanced User Guidebook Figure 5-69 Mean: The arithmetic mean over the entire waveform. PK-PK: Peak-to-Peak Voltage. RMS: The true Root Mean Square voltage over the entire waveform. Max: The maximum amplitude. The most positive peak voltage measured over the entire waveform. Min: The minimum amplitude.

  • Page 77: How To Measure With Cursors

    5.Advanced User Guidebook Figure 5-70 Rise Time: Time that the leading edge of the first pulse in the waveform takes to rise from 10% to 90% of its amplitude. Fall Time: Time that the falling edge of the first pulse in the waveform takes to fall from 90% to 10% of its amplitude.
  • Page 78 5.Advanced User Guidebook Figure 5-71 CURS MEAS Menu The description of the cursor measurement menu is shown as the following table: Function Setting Description Menu Switch off the cursor measurement. Type Voltage Display the voltage measurement cursor and menu. Time Display the time measurement cursor and menu.
  • Page 79 5.Advanced User Guidebook Carry out the following operation steps for the time cursor measurement of the channel CH1: Press Cursor and recall the Cursor Measure menu. 2. Press the H2 button and choose CH1 for Source. 3. Press the H1 button, the Type menu will display at the right of the screen. Press the F3 button to select Time for Type, with two purple dotted lines displayed along the vertical direction of the screen, which indicating Cursor 1 and Cursor 2.
  • Page 80 5.Advanced User Guidebook Figure 5-74 CURS MEAS Menu The description of the cursor measurement menu is shown as the following table: Function Setting Description Menu Switch off the cursor measurement. Type Vamp Display the Vamp measurement cursor and menu. Freq Display the Freq measurement cursor and menu.
  • Page 81 5.Advanced User Guidebook Figure 5-75 Wave of Vamp cursor measurement Carry out the following operation steps for the Freq cursor measurement: 1. Press Cursor and recall the Cursor Measure menu. 2. Press the H1 button, the Type menu will display at the right of the screen. Press the F3 button to select Freq for Type, with two purple dotted lines displayed along the vertical direction of the screen indicating the corresponding Cursor 1 and Cursor 2.

  • Page 82: How To Use Autoscale

    5.Advanced User Guidebook Figure 5-76 Wave of Freq cursor measurement How to Use Autoscale This is a very useful function for first time users to carry out a simple and quick test on the input signal. The function is applied to follow-up signals automatically even if the signals change at any time.

  • Page 83: How To Use Built-In Help

    5.Advanced User Guidebook Figure 5-78 Autoscale Horizontal-Vertical multi-period waveforms Note: ○ will be 1. Entering into Autoscale function and the symbol flickering on the top left of the screen every 0.5 second. 2. In the mode of Autoscale, the oscilloscope can self-estimate "Trigger Type" (Single, and Alternate) and "Mode"...

  • Page 84: How To Use Executive Buttons

    5.Advanced User Guidebook 4. Press H5 to exit the help, or just do other operations. How to Use Executive Buttons Executive Buttons include Autoset, Run/Stop, Single, Copy. Autoset It's a very useful and quick way to apply a set of pre-set functions to the incoming signal, and display the best possible viewing waveform of the signal and also works out some measurements for user as well.
  • Page 85 5.Advanced User Guidebook Description for some icons: Multi-period： To display multiple periods Single-period： To display single period FFT： Switch to FFT mode Rising Edge： Display the rising edge of square waveform Falling Edge： Display the falling edge of square waveform Cancel Autoset：Go back to display the upper menu and waveform information Run/Stop: Enable or disable sampling on input signals.

  • Page 86: Communication With Pc

    6.Communication with PC 6. Communication with PC Digital storage oscilloscope support communications with a PC through USB, LAN or COM port. You can use the Oscilloscope communication software to store, analyze, display the data and remote control. Here is how to connect with PC. First, install the Oscilloscope communication software on the supplied CD.

  • Page 87: Using Lan Port

    Here we set the IP address to 192.168.1.71. Figure 6-2 Set the network parameters of the computer (3) Set the network parameters of the OWON Oscilloscope Software. Run the software on the computer; choose the "Ports-settings" of the "Communications" menu item.

  • Page 88: Connect Through A Router

    6.Communication with PC Figure 6-3 Set the network parameters of the OWON Oscilloscope Software (4) Set the network parameters of the oscilloscope. In the oscilloscope, press the Utility button and press H1 button, turn the M knob to select the LAN Set; press the H2 button, the set menu is displayed on the right.
  • Page 89 192.168.1.1. Figure 6-5 Set the network parameters of the computer (3) Set the network parameters of the OWON Oscilloscope Software. Run the software on the computer; choose the "Ports-settings" of the "Communications" menu item. Set "Connect using" to LAN. About the IP, the first three bytes is same as the IP in the step (2), the last byte should be different.

  • Page 90: Using Com Port

    6.Communication with PC (4) Set the network parameters of the oscilloscope. In the oscilloscope, press the Utility button and press H1 button, turn the M knob to select the LAN Set; press the H2 button, the set menu is displayed on the right. Set the IP and the Port to the same value as the "Ports-settings"...

  • Page 91: Demonstration

    7.Demonstration 7. Demonstration Example 1: Measurement a Simple Signal The purpose of this example is to display an unknown signal in the circuit, and measure the frequency and peak-to-peak voltage of the signal. Carry out the following operation steps for the rapid display of this signal: (1) Set the probe menu attenuation coefficient as 10X and that of the switch in the probe switch as 10X (see "How to Set the Probe Attenuation Coefficient"...

  • Page 92: Example 2: Gain Of A Amplifier In A Metering Circuit

    7.Demonstration settings of channel 2. Then, the period, frequency, mean and peak-to-peak voltage will be displayed at the bottom left of the screen and change periodically (see Figure 7-1). Figure 7-1 Measure Frequency and PK-PK value for a given signal Example 2: Gain of a Amplifier in a Metering Circuit The purpose of this example is to work out the Gain of an Amplifier in a Metering Circuit.

  • Page 93: Example 3: Capturing A Single Signal

    7.Demonstration of the screen (See Figure 7-2). (9) Calculate the amplifier gain with the following formulas. Gain = Output Signal / Input signal Gain (db) = 20×log (gain) Figure 7-2 Waveform of Gain Measurement Example 3: Capturing a Single Signal It's quite easy to use Digital Oscilloscope to capture non-periodic signal, such as a pulse and burr etc.
  • Page 94 7.Demonstration (6) Press the Trigger Menu button to display the Trigger menu. (7) Press the H1 button to display the Trigger Type menu. (8) Press the F1 to choose Single as the type. (9) Turn the M knob to choose Edge as the mode. (10) Press the H2 button to display the Source menu.

  • Page 95: Example 4: Analyze The Details Of A Signal

    7.Demonstration Example 4: Analyze the Details of a Signal Noise is very common inside most of the electronic signal. To find out what's inside the noise and reduce the level of noise is very important function our oscilloscope is capable to offer. Noise Analysis The level of noise sometime indicates a failure of electronic circuit.

  • Page 96: Example 5: Application Of X-Y Function

    7.Demonstration (2) Press the H1 button to display ACQU Mode menu. (3) Press the F3 button, turn the M knob and observe the waveform obtained from averaging the waveforms of different average number. User would see a much reduced random noise level and make it easy to see more details of the signal itself.
  • Page 97 7.Demonstration (4) Turn the VOLTS/DIV knob, making the amplitudes of two signals equal in the rough. (5) Press the Display button and recall the Display menu. (6) Press the H3 button and choose XY Mode as ON. The oscilloscope will display the input and terminal characteristics of the network in the Lissajous graph form.

  • Page 98: Example 6: Video Signal Trigger

    7.Demonstration Example 6: Video Signal Trigger Observe the video circuit of a television, apply the video trigger and obtain the stable video output signal display. Video Field Trigger For the trigger in the video field, carry out operations according to the following steps: (1) Press the Trigger Menu button to display the trigger menu.

  • Page 99: Troubleshooting

    8.Troubleshooting 8. Troubleshooting 1. Oscilloscope is powered on but no Display.  Check whether the power connection is connected properly.  Check whether the fuse which is beside the AC power input jack is blew (the cover can be pried open with a straight screwdriver). ...

  • Page 100: Technical Specifications

    9.Technical Specifications 9. Technical Specifications Unless otherwise specified, the technical specifications applied are for SDS-E only, and Probes attenuation set as 10X. Only if the oscilloscope fulfills the following two conditions at first, these specification standards can be reached.  This instrument should run for at least 30 minutes continuously under the specified operating temperature.
  • Page 101 9.Technical Specifications Performance Characteristics Instruction Max. input voltage 400 V (DC + AC Peak) Channel –channel 50 Hz: 100 : 1 isolation 10 MHz: 40 : 1 Time delay between 150 ps channel(typical) 20 MHz, full bandwidth Bandwidth limit (Only SDS7102E(V) and SDS7122E(V) have this function) Dual CH 5 S/s –...
  • Page 102 9.Technical Specifications Performance Characteristics Instruction Single： Interval(△T) ± (1 interval time+100 ppm×reading+0.6 ns); accuracy Average>16： (DC - 100 MHz) ± (1 interval time+100 ppm×reading+0.4 ns) A/D converter 8 bits resolution (2 Channels simultaneously) SDS5032E(V) 5 mV/div – 5 V/div SDS5052E(V) SDS6062E(V) Sensitivity SDS7072E(V)
  • Page 103 9.Technical Specifications Performance Characteristics Instruction Period, Freq, Mean, PK-PK, RMS, Max, Min, Vtop, Vbase, Vamp, OverShoot, PreShoot, Rise Time, Fall Automatic Time, +D width, -D width, +Duty, -Duty, Delay A→B , Delay A→B , Cycle RMS, Cursor RMS, Duty cycle, and Phase. ＋, －, *, / ,FFT Waveform Math Waveform storage...
  • Page 104 9.Technical Specifications Performance Characteristics Instruction Pulse Width range 30 ns – 10 s Support standard NTSC, PAL and SECAM Modulation broadcast systems Video Trigger Line number range 1-525 (NTSC) and 1-625 (PAL/SECAM) Positive pulse：＞, ＜, ＝ Trigger condition negative pulse：＞, ＜, ＝ Slope Trigger Time setting 24 ns –...

  • Page 105: General Technical Specifications

    9.Technical Specifications General Technical Specifications Display Display Type 8" Colored LCD (Liquid Crystal Display) Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels Display Colors 65536 colors, TFT screen Output of the Probe Compensator Output Voltage About 5 V, with the Peak-to-Peak voltage ≥1 MΩ. (Typical ) Frequency (Typical ) Square wave of 1 KHz...

  • Page 106: Appendix

    10.Appendix 10. Appendix Appendix A: Enclosure Standard Accessories:  A pair of Passive probe: 1.2 m, 1:1 (10:1)  1 x CD (PC link application software)  1 x Power cord: up to the standards of the country in which it is used. ...
