SDS Series
Smart Digital Storage Oscilloscopes
User Manual
■ SDS6062(V)
■ SDS7072(V)
■ SDS7102(V)
■ SDS7202(V)
■ SDS8102(V)
■ SDS8202(V)
■ SDS8302
■ SDS9302
Note: "V" for VGA interface (optional);
SDS8302 and SDS9302 including VGA interface as default.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SDS7202 and is the answer not in the manual?

Questions and answers

Randy Jarvis
February 16, 2025

does SDS7102v have tracking cursors?

0
Randy Jarvis
February 16, 2025

is there trace intensity control?

0

Subscribe to Our Youtube Channel

Related Manuals for Owon SDS7202

Summary of Contents for Owon SDS7202

  • Page 1 SDS Series Smart Digital Storage Oscilloscopes User Manual ■ SDS6062(V) ■ SDS7072(V) ■ SDS7102(V) ■ SDS7202(V) ■ SDS8102(V) ■ SDS8202(V) ■ SDS8302 ■ SDS9302 Note: "V" for VGA interface (optional); SDS8302 and SDS9302 including VGA interface as default.
  • Page 2 LILLIPUT Company. Fujian LILLIPUT Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: www.owon.com.cn E-mail: info@owon.com.cn...
  • Page 3 OWON for warranty work may be new or reconditioned like new performance. All replaced parts, modules and products become the property of OWON. In order to obtain service under this warranty, customer must notify OWON of the defect before the expiration of the warranty period. Customer shall be responsible for packaging and shipping the defective product to the service center designated by OWON, and with a copy of customer proof of purchase.
  • Page 4 Table of Contents 1. General Safety Requirements ..................1 2. Safety Terms and Symbols ....................2 3. General Characteristics ....................4 4. Junior User Guidebook ....................5 Introduction to the Structure of the Oscilloscope ..............6 Front Panel ............................... 6 Left Side Panel ............................
  • Page 5 How to Cut and Recall a waveform ....................... 57 How to Record/Playback Waveforms ....................60 How to Implement the Auxiliary System Function Setting ..............65 How to Measure Automatically......................72 How to Measure with Cursors ........................ 75 How to Use Autoscale ..........................80 How to Use Built-in Help ........................
  • Page 6 1.General Safety Requirements 1. General Safety Requirements Before use, please read the following safety precautions to avoid any possible bodily injury and to prevent this product or any other connected products from damage. In order to avoid any contingent danger, ensure this product is only used within the range specified.
  • Page 7 2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property.
  • Page 8 2.Safety Terms and Symbols Warning The channels should adopt common basis during measuring. To prevent short circuits, the 2 probe ground must not be connected to 2 different non-isolated DC level. The diagram of the oscilloscope ground wire connection: Probe Oscilloscope Electrical Outlet Signal Input...
  • Page 9 3.General Characteristics 3. General Characteristics  Bandwidth: 60 MHz - 300 MHz;  Sample rate(real time): 500 MS/s - 3.2 GS/s;  Dual channel, 10M points on each channel for the Record length;  Autoscale function;  7cm smart design body; ...
  • Page 10 4.Junior User Guidebook 4. Junior User Guidebook This chapter deals with the following topics mainly:  Introduction to the structure of the oscilloscope  Introduction to the user interface  How to implement the general inspection  How to implement the function inspection ...
  • Page 11 4.Junior User Guidebook Introduction to the Structure of the Oscilloscope When you get a new-type oscilloscope, you should get acquainted with its front panel at first and the digital storage oscilloscope is no exception. This chapter makes a simple description of the operation and function of the front panel of the oscilloscope, enabling you to be familiar with the use of the oscilloscope in the shortest time.
  • Page 12 4.Junior User Guidebook 4. Control (key and knob) area 5. Probe Compensation: Measurement signal (5V/1KHz) output. (The signal parameters could be adjusted in SDS7072(V), refer to "Signal" on P71) 6. EXT Trigger Input 7. Signal Input Channel 8. Menu off Left Side Panel Figure 4-2 Left side panel 1.
  • Page 13 4.Junior User Guidebook 2. USB Device port: It is used to transfer data when external USB equipment connects to the oscilloscope regarded as "slave device". For example: to use this port when connect PC to the oscilloscope by USB. 3. COM / VGA port (Optional): To connect the oscilloscope with external equipment as serial port, or to connect the oscilloscope with a monitor or a projector as VGA output (for the model with "V") 4.
  • Page 14 4.Junior User Guidebook Control (key and knob) Area Figure 4-5 Keys Overview 1. Menu option setting: H1 - H5 2. Menu option setting: F1 - F5 3. Menu off：turn off the menu ○ 4. M knob(Multipurpose knob): when a M symbol appears in the menu, it indicates you can turn the M knob to select the menu or set the value.
  • Page 15 4.Junior User Guidebook User Interface Introduction Figure 4-6 Illustrative Drawing of Display Interfaces 1. Waveform Display Area. The state of trigger, including: Auto: Automatic mode and acquire waveform without triggering. Trig: Trigger detected and acquire waveform. Ready: Pre-triggered data captured and ready for a trigger. Scan: Capture and display the waveform continuously.
  • Page 16 4.Junior User Guidebook 11. The waveform of CH1. 12. The positions of two purple dotted line cursors measurements. 13. The yellow pointer shows the trigger level position for CH2. 14. The waveform of CH2. 15. The frequency of the trigger signal of CH1. 16.
  • Page 17 Manual. You can check whether there is any loss of accessories with reference to this description. If it is found that there is any accessory lost or damaged, please get in touch with the distributor of OWON responsible for this service or the OWON's local offices.
  • Page 18 4.Junior User Guidebook Connect the probe tip and the ground clamp to the connector of the probe compensator. 3. Press the "Autoset" Button. The square wave of 1 KHz frequency and 5V peak-peak value will be displayed in several seconds (see Figure 4-7). Figure 4-7 Auto set Check CH2 by repeating Step 2 and Step 3.
  • Page 19 4.Junior User Guidebook Overcompensated Compensated correctly Under compensated Figure 4-8 Displayed Waveforms of the Probe Compensation Repeat the steps mentioned if needed. Figure 4-9 Adjust Probe How to Set the Probe Attenuation Coefficient The probe has several attenuation coefficients, which will influence the vertical scale factor of the oscilloscope.
  • Page 20 4.Junior User Guidebook Figure 4-10 Attenuation Switch Caution: When the attenuation switch is set to 1X, the probe will limit the bandwidth of the oscilloscope in 5MHz. To use the full bandwidth of the oscilloscope, the switch must be set to 10X. How to Use the Probe Safely The safety guard ring around the probe body protects your finger against any electric shock, shown as Figure 4-11.
  • Page 21 4.Junior User Guidebook menu; turn the M knob to choose Adjust. Press H2 button to choose the option "Self Cal"; run the program after everything is ready. Introduction to the Vertical System As shown in Figure 4-12, there are a few of buttons and knobs in VERTICAL CONTROLS.
  • Page 22 4.Junior User Guidebook  Turn the vertical "VOLTS/DIV" knob and change the "Vertical Scale Factor (Voltage Division)", it can be found that the scale factor of the channel corresponding to the status bar has been changed accordingly.  Press buttons of "CH1 MENU", "CH2 MENU" and "Math", the operation menu, symbols, waveforms and scale factor status information of the corresponding channel will be displayed in the screen.
  • Page 23 4.Junior User Guidebook Introduction to the Trigger System As shown in Figure 4-14, there are one knob and three buttons make up "TRIGGER CONTROLS". The following practices will direct you to be familiar with the setting of the trigger system gradually. Figure 4-14 Trigger Control Zone Press the "Trigger Menu"...
  • Page 24 5.Advanced User Guidebook 5. Advanced User Guidebook Up till now, you have already been familiar with the basic operations of the function areas, buttons and knobs in the front panel of the oscilloscope. Based the introduction of the previous Chapter, the user should have an initial knowledge of the determination of the change of the oscilloscope setting through observing the status bar.
  • Page 25 5.Advanced User Guidebook How to Set the Vertical System The VERTICAL CONTROLS includes three menu buttons such as CH1 MENU, CH2 MENU and Math, and four knobs such as VERTICAL POSITION, VOLTS/DIV for each channel. Setting of CH1 and CH2 Each channel has an independent vertical menu and each item is set respectively based on the channel.
  • Page 26 5.Advanced User Guidebook The description of the Channel Menu is shown as the following list: Function Setting Description Menu Pass both AC and DC components of the input signal. Coupling Block the DC component of the input signal. GROUND Disconnect the input signal. Display inverted waveform.
  • Page 27 5.Advanced User Guidebook Figure 5-2 DC Coupling Oscillogram Figure 5-3 AC Coupling Oscillogram 2. To adjust the probe attenuation For correct measurements, the attenuation coefficient settings in the operating menu of the Channel should always match what is on the probe (see "How to Set the Probe Attenuation Coefficient"...
  • Page 28 5.Advanced User Guidebook (1) Press the CH1 MENU button to show the CH1 SETUP menu. (2) Press the H3 menu selection, the Probe menu will display at the right of the screen. Press the F1 button to select Attenu. In the menu at the left of the screen, turn the M knob to select X10 for the probe.
  • Page 29 5.Advanced User Guidebook Figure 5-5 Measure Current 4. To invert a waveform Waveform inverted: the displayed signal is turned 180 degrees against the phase of the earth potential. Taking the Channel 1 for example, the operation steps are shown as follows: (1) Press the CH1 MENU button to show the CH1 SETUP menu.
  • Page 30 5.Advanced User Guidebook Figure 5-6 Original Waveform Figure 5-7 Inverted Waveform 5. To set bandwidth limit (SDS6062(V), SDS7072(V) does not have this function) When high frequency components of a waveform are not important to its analysis, the bandwidth limit control can be used to reject frequencies above 20 MHz. Taking the Channel 1 for example, the operation steps are shown as below: (1) Press the CH1 MENU button to show CH1 SETUP menu.
  • Page 31 5.Advanced User Guidebook (3) Press the F1 button to select the Band Limit as full band. The high frequency of the signal will be allowed to pass. (4) Press the F2 button to select the Band Limit as 20M. The bandwidth is limited to 20MHz.
  • Page 32 5.Advanced User Guidebook Hamming Rectangle Window Select window for FFT. Blackman Hanning Select dB for Format. Format Vrms Select Vrms for Format. ×1 Set multiple ×1. ×2 Set multiple ×2. Zoom ×5 Set multiple ×5. ×10 Set multiple ×10. channel Select channel low-pass high-pass...
  • Page 33 5.Advanced User Guidebook Press the F4 menu selection button and choose VERT POS, turn the M knob to adjust the vertical position of M waveform. Press the F5 menu selection button and choose VOLTS/DIV, turn the M knob to adjust the voltage division of M waveform. Figure 5-9 Waveform resulted from CH1 +CH2 Using FFT function The FFT (fast Fourier transform) math function mathematically converts a time-domain...
  • Page 34 5.Advanced User Guidebook magnitude accuracy. What you want to measure and your source signal characteristics help you to determine which window to use. Use the following guidelines to select the best window. Type Characteristics Window Better solution for magnitude than Rectangle, and good for frequency as well.
  • Page 35 5.Advanced User Guidebook with a frequency of 1kHz under the selection of four different windows for FFT: Figure 5-10 Hamming window Figure 5-11 Rectangle window...
  • Page 36 5.Advanced User Guidebook Figure 5-12 Blackman window Figure 5-13 Hanning window Notes for using FFT  Use Zoom function to magnify the FFT waveform if necessary.  Use the default dB scale for details of multiple frequencies, even if they have very different amplitudes.
  • Page 37 5.Advanced User Guidebook What is Nyquist frequency? The Nyquist frequency is the highest frequency that any real-time digitizing oscilloscope can acquire without aliasing. This frequency is half of the sample rate. Frequencies above the Nyquist frequency will be under sampled, which causes aliasing. So pay more attention to the relation between the frequency being sampled and measured.
  • Page 38 5.Advanced User Guidebook value is displayed at the left bottom corner of the screen (see Figure 5-14). Figure 5-14 Information about Vertical Position How to Set the Horizontal System The HORIZONTAL CONTROLS includes the HORIZ MENU button and such knobs as HORIZONTAL POSITION and SEC/DIV. HORIZONTAL POSITION knob: this knob is used to adjust the horizontal positions of all channels (include those obtained from the mathematical manipulation), the analytic resolution of which changes with the time base.
  • Page 39 5.Advanced User Guidebook expanded to the full screen. Main Time Base Press the H1 menu selection button and choose Main. In this case, the HORIZONTAL POSITION and SEC/DIV knobs are used to adjust the main window. The display in the screen is shown as Figure 5-16. Figure 5-16 Main Time Base Set Window Press the H2 menu selection button and choose Set.
  • Page 40 5.Advanced User Guidebook Figure 5-17 Window Setting Window Expansion Press the H3 menu selection button and choose Zoom. As a result, the window area defined by two cursors will be expanded to the full screen size (see Figure 5-18). Figure 5-18 Zoom Window...
  • Page 41 5.Advanced User Guidebook How to Set the Trigger System Trigger determines when DSO starts to acquire data and display waveform. Once trigger is set correctly, it can convert the unstable display to meaningful waveform. When DSO starts to acquire data, it will collect enough data to draw waveform on left of trigger point.
  • Page 42 5.Advanced User Guidebook The Edge Trigger Menu is shown as Figure 5-19 Figure 5-19 Edge trigger menu Edge menu list: Menu Settings Instruction Single Mode Edge Set vertical channel trigger type as edge trigger. Channel 1 as trigger signal. Channel 2 as trigger signal. Source External trigger as trigger signal EXT/5...
  • Page 43 5.Advanced User Guidebook Figure 5-20 Video trigger menu Video menu list: MENU SETTING INSTRUCTION Single Mode Video Set vertical channel trigger type as video trigger Select CH1 as the trigger source Select CH2 as the trigger source Source The external trigger input EXT/5 1/5 of the external trigger source for increasing range of level...
  • Page 44 5.Advanced User Guidebook Set slope condition; turn the M knob to set slope time. High level Adjust M knob to set the High level upper limit. Threshold Low level Adjust M knob to set Low level lower limit. &SlewRate Slew rate Slew rate = (High level - Low level) / Settings Auto Acquire waveform even no trigger occurred...
  • Page 45 5.Advanced User Guidebook Auto Acquire waveform even no trigger occurred Normal Acquire waveform when trigger occurred Mode Single When trigger occurs, acquire one waveform then stop Holdoff 100 ns - 10 s, adjust M knob to set time interval Holdoff before another trigger occur.
  • Page 46 5.Advanced User Guidebook 2. Alternate trigger (Trigger Mode: video) Alternate trigger (Trigger Type: video) Menu is shown as Figure 5-24. Figure 5-24 Alternate trigger (Trigger Type: video) Menu Alternate trigger (Trigger Type: video) list: Menu MENU SETTING INSTRUCTION Alternate Mode Video Set vertical channel trigger type as video trigger.
  • Page 47 5.Advanced User Guidebook Turn the M knob to set the High level High level Turn the M knob to set Threshold Low level Low level Slew rate=( Slew rate High level- Low level)/ Settings Auto Acquire waveform even no trigger occurred Mode Holdoff 100 ns - 10 s, adjust the M knob to set time interval...
  • Page 48 5.Advanced User Guidebook selected as a trigger source whatever displayed or not.  Ext Trig: The instrument can be triggered from a third source while acquiring data from CH1 and CH2. For example, to trigger from an external clock or with a signal from another part of the test circuit.
  • Page 49 5.Advanced User Guidebook How to Operate the Function Menu The function menu control zone includes 8 function menu buttons: Measure, Acquire, Utility, Cursor, Autoscale, Save, Display, Help and 4 immediate-execution buttons: Autoset, Run/Stop, Single, Copy. How to Implement Sampling Setup Press the Acquire button and the menu is displayed in the screen, shown as Figure 5-27.
  • Page 50 5.Advanced User Guidebook The description of the Record Length Menu is shown as follows: Function Menu Setting Description 1000 Length 100K Choose the record length Change the ACQU Mode settings and observe the consequent variation of the wave form displayed. Figure 5-28 Peak Detect mode, under which the burrs on the falling edge of the square wave, can be detected and the noise is heavy.
  • Page 51 5.Advanced User Guidebook Figure 5-30 The displayed waveform after the noise is removed under the Average Mode, in which the average number of 16 is set. How to Set the Display System Press the Display button and the menu displayed in the screen is shown as Figure 5-31.
  • Page 52 5.Advanced User Guidebook Display Type: With the F1 menu selection button pushed down, you can shift between Vect and Dots types. The differences between the two display types can be observed through the comparison between Figure 5-32 and Figure 5-33. Figure 5-32 Display in the Vector Form Figure 5-33 Display in Dots form Persist...
  • Page 53 5.Advanced User Guidebook OFF, 1second, 2second, 5second and Infinity. When the "Infinity" option is set for Persist time, the measuring points will be stored till the controlling value is changed (see Figure 5-34). By pressing the F2 button, the persistence will be cleared. Figure 5-34 Infinite Persistence Display XY Format This format is only applicable to Channel 1 and Channel 2.
  • Page 54 5.Advanced User Guidebook Operation steps: Press the Display button and call out the Display Set Menu. Press the H3 menu selection button to set XY Mode ON. The display format is changed to be XY mode (see Figure 5-35). Figure 5-35 XY Display Mode Trig Freq It is a 6-digit trig freq.
  • Page 55 (see " " on P45); Record Length Menu External the file name is editable. The waveform file could be open by OWON waveform analysis software (on the supplied CD). When the type is Setting, the menu shows as following:...
  • Page 56 5.Advanced User Guidebook Setting1 ….. Setting The setting address Setting8 Save the current oscilloscope setting to the Save internal storage Load Recall the setting from the selected address When the type is Image, the menu shows as following: Save the current display screen. The file can be only stored in a USB storage, so a Save USB storage must be connected first.
  • Page 57 5.Advanced User Guidebook Figure 5-37 Wave Saving Tip: Whatever the Type of save menu is set, you can save the waveform by just pressing the Copy panel button in any user interface. If the Storage of the save menu is set as "External", you should install the USB disk.
  • Page 58 5.Advanced User Guidebook Delete the last character End and store Switch between Close the keyboard capital and small Figure 5-38 Edit the File Name USB disk Requirements The supported format of the USB disk: FAT32 file system, the allocation unit size cannot exceed 4K, mass storage USB disk is also supported.
  • Page 59 5.Advanced User Guidebook Figure 5-39: Disk Management of computer 4. Right click 1 or 2 red mark area, choose Format. And system will pop up a warning message, click Yes. Figure 5-40: Format the USB disk warning 5. Set File System as FAT32, Allocation unit size 4096. Check "Perform a quick format"...
  • Page 60 5.Advanced User Guidebook Figure 5-42: Formatting the USB disk Check whether the USB disk is FAT32 with allocation unit size 4096 after formatting. Use Minitool Partition Wizard to format Download URL: http://www.partitionwizard.com/free-partition-manager.html Tip: There are many tools for the USB disk formatting on the market, just take Minitool Partition Wizard for example here.
  • Page 61 5.Advanced User Guidebook Figure 5-43: Reload Disk 4. Right click 1 or 2 red mark area, choose Format. Figure 5-44: Choose format 5. Set File System FAT32, Cluster size 4096. Click OK. Figure 5-45: Format setting 6. Click Apply at the top left of the menu. Then click Yes on the pop-up warning to begin formatting.
  • Page 62 To cut waveform between two time cursors, generate a file with the suffix “*.ota”, and save it to external memory device. To recall the waveform is to use AG1022F or AG2052F manufactured by OWON to read *.ota and recall the waveform being cut from oscilloscope.
  • Page 63 5.Advanced User Guidebook 2. Press Save to call out the save menu 3. Press the H1 button, the type menu will display at the left of the screen, turn the M knob to choose Cut Wave for type. Move cursor1 (CH1 zero position knob) and cursor2 (CH2 zero position knob) to choose the range of wave to be cut.
  • Page 64 5.Advanced User Guidebook (2) Select USBDEVICE, enter Next Level. Turn the knob or press direction key to select the saved example.ota waveform file. Figure 5-51: choose the .ota file (3) Choose Recall output. And the tip “Read file successfully” will show on the interface.
  • Page 65 5.Advanced User Guidebook How to Record/Playback Waveforms Wave Record function can record the input current wave. You can set the interval between recorded frames in the range of 1 ms - 1000 s.The max frame number reaches 1000,and you can get better analysis effect with playback and storage function. The storage medium contains two kinds: Internal and External.
  • Page 66 5.Advanced User Guidebook Figure 5-53 Wave Record Playback: Play back the wave recorded or saved. Playback menu shows as follows: Menu Setting Instruction Start frame Turn the M knob to select the number of start frame to playback (1 - 1000) End frame Turn the M knob to select the number of end frame Playback Mode...
  • Page 67 5.Advanced User Guidebook Figure 5-54 Wave Playback Storage: Save the current wave according to the start frame and end frame set. Storage menu shows as follows: Menu Setting Instruction Turn the M knob to select the number of start frame Start frame Storage to store (1 - 1000)
  • Page 68 5.Advanced User Guidebook To use wave record function, do as follows: (1) Press Save button. (2) Press H1 button, turn the M knob to choose Record. (3) Press H2 button. In the Mode menu, press F2 button to choose Record. (4) Press H3 button.
  • Page 69 5.Advanced User Guidebook Play Begin to record Operate Stop Stop recording Note: Both of the waveforms of Channel 1 and Channel 2 will be recorded. If a Channel is turned off while recording, the waveform of the channel is invalid in the playback mode.
  • Page 70 5.Advanced User Guidebook Figure 5-58: Play back waveform by software How to Implement the Auxiliary System Function Setting ●Config Press the Utility button and turn the M knob to select Config to go to the following menu. Figure 5-59 Configuration Menu The description of Configuration Menu is shown as the follows:...
  • Page 71 5.Advanced User Guidebook Function Menu Setting Description Chinese Choose the display language of the operating Language English system. Others Display On/Off the date display Set Time Hour Min Setting Hour/Minute Day Month Setting Date/Month Year Setting Year Lock all keys. Unlock method: press 50% KeyLock button in trigger control area, then press Force button, repeat 3 times.
  • Page 72 5.Advanced User Guidebook The description of Adjust Menu is shown as the follows: Function Menu Setting Description Self Cal Carry out the self-calibration procedure. Default Call out the factory settings. ProbeCh. Check whether probe attenuation is good. Do Self Cal (Self-Calibration) The self-calibration procedure can improve the accuracy of the oscilloscope under the ambient temperature to the greatest extent.
  • Page 73 5.Advanced User Guidebook 4. Press H4 again to begin probe checking and the checking result will occur after 3s; Press any other key to quit. Figure 5-63：Probe Checking ● Pass/Fail The Pass/Fail function monitors changes of signals and output pass or fail signals by comparing the input signal that is within the pre-defined mask.
  • Page 74 5.Advanced User Guidebook The description of Pass/Fail Menu is shown as the follows: Function Menu Setting Description Enable Control enable switch operate Operate Control operate switch Pass Signal tested corresponds with the rule Fail Signal tested not correspond with the rule Output Beep Beep when it satisfies the rule...
  • Page 75 5.Advanced User Guidebook Figure 5-65 Pass/Fail test Note: 1. When Pass/Fail is ON, if XY or FFT is ready to run, then Pass/Fail will be closed; under the mode of XY or FFT, Pass/Fail is unable. 2. Under the mode of Factory, Auto Scale and Auto Set, Pass/Fail will be closed. 3.
  • Page 76 5.Advanced User Guidebook ● LAN Set Using the LAN port, the oscilloscope can be connected with a computer directly, or through the router to connect. The network parameters can be set in the menu below. Refer to "Using LAN Port" on P85 for the operation steps. Press the Utility button and turn the M knob to select the LAN Set to go to the following menu.
  • Page 77 5.Advanced User Guidebook How to Measure Automatically Press the Measure button to display the menu for the settings of the Automatic Measurements. At most 8 types of measurements could be displayed on the bottom left of the screen. The oscilloscopes provide 24 parameters for auto measurement, including Period, Freq, Mean, PK-PK, RMS, Max, Min, Vtop, Vbase, Vamp, OverShoot, PreShoot, Rise Time, Fall Time, +D width, -D width, +Duty, -Duty, Delay A→B , Delay A→B , Cycle RMS, Cursor RMS, Duty cycle, and Phase.
  • Page 78 5.Advanced User Guidebook waveform channel is in the ON state, the measurement can be performed. The automatic measurement cannot be performed in the following situation: 1) On the saved waveform. 2) On the mathematical waveform. 3) On the XY format. 4) On the Scan format.
  • Page 79 5.Advanced User Guidebook Figure 5-70 automatic measurement The automatic measurement of voltage parameters The oscilloscopes provide automatic voltage measurements including Mean, PK-PK, RMS, Max, Min, Vtop, Vbase, Vamp, OverShoot, PreShoot, Cycle RMS, and Cursor RMS. Figure 5-71 below shows a pulse with some of the voltage measurement points.
  • Page 80 5.Advanced User Guidebook A→B , Delay A→B , and Duty cycle. Figure 5-72 shows a pulse with some of the time measurement points. Figure 5-72 Rise Time: Time that the leading edge of the first pulse in the waveform takes to rise from 10% to 90% of its amplitude.
  • Page 81 5.Advanced User Guidebook at normal mode, shown as Figure 5-73. Figure 5-73 CURS MEAS Menu The description of the cursor measurement menu is shown as the following table: Function Setting Description Menu Switch off the cursor measurement. Type Voltage Display the voltage measurement cursor and menu. Time Display the time measurement cursor and menu.
  • Page 82 5.Advanced User Guidebook Figure 5-74 Waveform of Voltage Cursor Measurement Carry out the following operation steps for the time cursor measurement of the channel CH1: Press Cursor and recall the Cursor Measure menu. Press the H2 button and choose CH1 for Source. Press the H1 button, the Type menu will display at the right of the screen.
  • Page 83 5.Advanced User Guidebook Figure 5-75 Waveform of Cursor Measurement The Cursor Measurement for FFT mode: Press the Cursor button to display the cursor measurement function menu (CURS MEAS) in the screen, which includes Vamp Measurement and Freq Measurement at the mode of FFT, shown as Figure 5-76. Figure 5-76 CURS MEAS Menu The description of the cursor measurement menu is shown as the following table: Function...
  • Page 84 5.Advanced User Guidebook Source Math FFT Display the channel for the cursor measure. When carrying out the cursor measurement, the position of Cursor 1 can be adjusted with the VERTICAL POSITION knob of Channel 1, and that of Cursor 2 can be adjusted with the VERTICAL POSITION knob of Channel 2.
  • Page 85 5.Advanced User Guidebook Cursor2 by turning the VERTICAL POSITION knob of CH1 and CH2. Increment window shows two cursors difference value and the present position (see Figure 5-78). Figure 5-78 wave of Freq cursor measurement How to Use Autoscale This is a very useful function for first time users to carry out a simple and quick test on the input signal.
  • Page 86 5.Advanced User Guidebook Turn on Autoscale. Autoscale Turn off Autoscale. Follow-up and adjust both vertical and horizontal settings. Follow-up and only adjust horizontal scale. Mode Follow-up and only adjust vertical scale. Show Multi-period waveforms. Wave Only show one or two periods. If you want to measure the two-channel signal, you can do as the follows: 1.
  • Page 87 5.Advanced User Guidebook 3. At the mode of XY and STOP status, pressing Autoset to enter into Autoscale, DSO switches to YT mode and AUTO triggering. 4. At the mode of Autoscale, DSO is always set as DC coupling with AUTO triggering.
  • Page 88 5.Advanced User Guidebook Trigger Mode Auto Display Format Judge waveform type by Autoset Five kinds of types: Sine, Square, video signal, DC level, Unknown signal. Menu as follow: Sine: ( Multi-period, Single-period, FFT, Cancel Autoset Square: ( Multi-period, Single-period, Rising Edge, Falling Edge, Cancel Autoset Video signal: DC level, Unknown signal: Description for some icons:...
  • Page 89 6.Communication with PC 6. Communication with PC Digital storage oscilloscope support communications with a PC through USB, LAN or COM port. You can use the Oscilloscope communication software to store, analyze, display the data and remote control. Here is how to connect with PC. First, install the Oscilloscope communication software on the supplied CD.
  • Page 90 Here we set the IP address to 192.168.1.71. Figure 6-2 Set the network parameters of the computer (3) Set the network parameters of the OWON Oscilloscope Software. Run the software on the computer; choose the "Ports-settings" of the "Communications" menu item.
  • Page 91 6.Communication with PC Figure 6-3 Set the network parameters of the OWON Oscilloscope Software (4) Set the network parameters of the oscilloscope. In the oscilloscope, press the Utility button and press H1 button, turn the M knob to select the LAN Set; press the H2 button, the set menu is displayed on the right.
  • Page 92 192.168.1.1. Figure 6-5 Set the network parameters of the computer (3) Set the network parameters of the OWON Oscilloscope Software. Run the software on the computer; choose the "Ports-settings" of the "Communications" menu item. Set "Connect using" to LAN. About the IP, the first three bytes is same as the IP in the step (2), the last byte should be different.
  • Page 93 6.Communication with PC (4) Set the network parameters of the oscilloscope. In the oscilloscope, press the Utility button and press H1 button, turn the M knob to select the LAN Set; press the H2 button, the set menu is displayed on the right. Set the IP and the Port to the same value as the "Ports-settings"...
  • Page 94 7.Demonstration 7. Demonstration Example 1: Measurement a Simple Signal The purpose of this example is to display an unknown signal in the circuit, and measure the frequency and peak-to-peak voltage of the signal. Carry out the following operation steps for the rapid display of this signal: (1) Set the probe menu attenuation coefficient as 10X and that of the switch in the probe switch as 10X (see "How to Set the Probe Attenuation Coefficient"...
  • Page 95 7.Demonstration settings of channel 2. Then, the period, frequency, mean and peak-to-peak voltage will be displayed at the bottom left of the screen and change periodically (see Figure 7-1). Figure 7-1 Measure Frequency and PK-PK value for a given signal Example 2: Gain of a Amplifier in a Metering Circuit The purpose of this example is to work out the Gain of an Amplifier in a Metering Circuit.
  • Page 96 7.Demonstration of the screen (see Figure 7-2). (9) Calculate the amplifier gain with the following formulas. Gain = Output Signal / Input signal Gain (db) = 20×log (gain) Figure 7-2 Waveform of Gain Measurement Example 3: Capturing a Single Signal It's quite easy to use Digital Oscilloscope to capture non-periodic signal, such as a pulse and burr etc.
  • Page 97 7.Demonstration (6) Press the Trigger Menu button to display the Trigger menu. (7) Press the H1 button to display the Trigger Type menu. (8) Press the F1 to choose Single as the type. (9) Turn the M knob to choose Edge as the mode. (10) Press the H2 button to display the Source menu.
  • Page 98 7.Demonstration Example 4: Analyze the Details of a Signal Noise is very common inside most of the electronic signal. To find out what's inside the noise and reduce the level of noise is very important function our oscilloscope is capable to offer. Noise Analysis The level of noise sometime indicates a failure of electronic circuit.
  • Page 99 7.Demonstration (2) Press the H1 button to display ACQU Mode menu. (3) Press the F3 button, turn the M knob and observe the waveform obtained from averaging the waveforms of different average number. User would see a much reduced random noise level and make it easy to see more details of the signal itself.
  • Page 100 7.Demonstration (4) Turn the VOLTS/DIV knob, making the amplitudes of two signals equal in the rough. (5) Press the Display button and recall the Display menu. (6) Press the H3 button and choose XY Mode as ON. The oscilloscope will display the input and terminal characteristics of the network in the Lissajous graph form.
  • Page 101 7.Demonstration Example 6: Video Signal Trigger Observe the video circuit of a television, apply the video trigger and obtain the stable video output signal display. Video Field Trigger For the trigger in the video field, carry out operations according to the following steps: (1) Press the Trigger Menu button to display the trigger menu.
  • Page 102  Restart the instrument after completing the checks above.  If the problem persists, please contact OWON and we will be under your service. 2. After acquiring the signal, the waveform of the signal is not displayed in the screen.
  • Page 103 All specification standards can be fulfilled, except one(s) marked with the word "Typical". Performance Characteristics Instruction SDS6062(V) 60 MHz SDS7072(V) 70 MHz SDS7102(V) 100 MHz SDS7202(V) 200 MHz Bandwidth SDS8102(V) 100 MHz SDS8202(V) 200 MHz SDS8302 300 MHz SDS9302 300 MHz...
  • Page 104 0.5S/s - 500MS/s Dual CH 0.5S/s - 500MS/s SDS7072(V) Single CH 0.5S/s - 1GS/s SDS7102(V) Dual CH 0.5S/s - 500MS/s SDS7202(V) Single CH 0.5S/s - 1GS/s Dual CH 0.5S/s - 1GS/s Sampling rate range SDS8102(V) Single CH 0.5S/s - 2GS/s Dual CH 0.5S/s - 1GS/s...
  • Page 105 2 ns/div – 100 s/div, SDS7072(V) step by 1 - 2 - 5 SDS7102(V) 2 ns/div – 100 s/div, SDS7202(V) step by 1 - 2 - 5 Scanning speed 1 ns/div – 100 s/div, SDS8102(V) step by 1 - 2 - 5 (S/div) 1 ns/div –...
  • Page 106 SDS6062(V) ≤ 5.8 ns (at input, Typical) SDS7072(V) ≤ 5.0 ns (at input, Typical) SDS7102(V) ≤ 3.5 ns (at input, Typical) SDS7202(V) ≤ 1.7 ns (at input, Typical) Rise time SDS8102(V) ≤ 3.5 ns (at input, Typical) SDS8202(V) ≤ 1.7 ns (at input, Typical) ≤...
  • Page 107 9.Technical Specifications Performance Characteristics Instruction USB 2.0, USB for file storage; LAN port; Communication VGA interface ( only for the model with "V" or the models including VGA port ) or RS-232 (Optional); interface as default Trigger: Performance Characteristics Instruction Internal ±6 div from the screen center Trigger level range...
  • Page 108 9.Technical Specifications General Technical Specifications Display Display Type 8" Colored LCD (Liquid Crystal Display) Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels Display Colors 65536 colors, TFT screen Output of the Probe Compensator Output Voltage ≥1 MΩ. About 5 V, with the Peak-to-Peak voltage (Typical ) Frequency (Typical )
  • Page 109 10.Appendix 10. Appendix Appendix A: Enclosure Standard Accessories:  A pair of Passive probe: 1.2 m, 1:1 (10:1)  1x CD (PC link application software)  1x Power cord: up to the standards of the country in which it is used. ...
  • Page 110 10.Appendix Appendix C: Battery Using Guide Battery level indicator 、 、 and include: Figure 10-1 Battery level indicator Charging the oscilloscope Connect the power cord to a power source. Turn on the Power Switch Button ― ○ on the left side (make sure the "―" side is pressed down). Yellow light of the indicator on the front panel means the battery is being charged.
