- Vehicle connections -

Tip

• • You will need to purchase the necessary component adapter cable for the vehicle so that the power

supplies can be utilized. (Contact the dealer for further details.)

• • Be sure to wrap the connection cables with plastic tape to insulate them.

- Example of using vehicle adapter cables -

Power supplies

for combined

products

From main unit

Vehicle component adapter cable

- 9 -

Vehicle harness
