Wire colors and connection points for connection cables
Never connect the power supply to the speaker leads (No.6 and No.7),
otherwise it will cause damage to the main unit.
Caution
1
B+ (Yellow)
Connect where power is constantly available, regardless of the ignition key's position.
ACC (Red)
2
Connect where the power comes on when the ignition is in the ACC position.
Illumination power supply (Orange/White)
3
Connect to where power comes on when the vehicle light switch is turned on.
Antenna power supply (Blue)
4
Connect to the automatic-antenna control terminal of the vehicle.
5
Control power supply (Blue/White)
Connect the control terminal for the external amplifier, etc.
6
Front speaker output leads
Connect to the front speakers.
Rear speaker output leads
7
Connect to the rear speakers.
Ground (Black)
8
Connect where good body grounding is available.
Vehicle speed pulse signal wire (Purple/White)
9
Connect to the vehicle speed pulse signal terminal.
10
Parking brake signal wire (Red/White)
Connect to the parking brake signal terminal.
Reverse signal Wire (Green)
11
Connect the reverse signal output of the vehicle to this terminal.
Navi mute Wire (Brown)
12
Connect to the NAVI-MUTE terminal of a DCU105 or similar device (sold separately).
Cellular phone mute Wire (Pink)
13
Connect to the ground output terminal on a mobile phone.
14
H/A mute Wire (Light Green)
Connect to the DVD-MUTE terminal of a DCU105 or similar device (sold separately).
White:
Left +
Gray:
Right +
Green: Left +
Purple: Right +
- 7 -
and
2
White/black:
Left -
Gray/Black:
Right -
Green/black:
Left -
Purple/Black:
Right -
and
3
4
