Components
Components
Main unit components
1 Main unit
x 1
Antenna cable
5
x 1
Case
9
(For detachable panel) x 1
13 Pan screw with washer
(Blue:M4x3) x 4
GPS antenna components
14 GPS antenna
x 1
Wiring components
Clamp (for GPS antenna)
18
x 3
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting cable
2
(Power and speaker connector)
(16P) x 1
Bezel
6
x 1
Splicing connector
10
x 3
16
Waterproof cushion
15
x 1
Cable tie
19
x 4
Interconnecting cable
3
(Speed pulse, parking,
reverse,video, etc)
(20P) x 1
Mounting sleeve
7
x 1
Flat head screw
11
(M4x6) x 4
Body protective sheet
Ground plate 17
x 1
Harness affixing tape
20
x 3
- 2 -
Interconnecting cable
4
(E-lan etc)
(16P) x 1
Side bracket
8
x 2
12
Thin flat screw
(M4x5) x 4
x 1
