Eclipse AVN7000 Installation Manual page 20

4
Insert the main unit into the mounting sleeve until
it locks in place.
5
Fasten the rear of the main unit.
6 Install the bezel on the main unit.
-Mounting the main unit (If installing the main unit using the side brackets of the vehicle)-
Tip
Connect all cables before installing the main
unit.
1 Remove the pocket and any other accessories
from the center cluster to make room for the main
unit.
Remove the mounting brackets for the pocket.
2
3 Attach the brackets to the main unit.
Tip
Be sure to use the supplied accessory mounting
screws (M4 x 5) as the mounting screws. If any
other screws are used, they may damage the
inside of the unit.
4 Install the main unit in the vehicle.
Tip
Be careful not to forcefully push on the main unit's
display or buttons during installation. This may
result in damage to the main unit.
Dashboard or console box
Center cluster panel
Pocket, etc
If using these installation holes, be sure to use
the
13
Main unit
1
Pocket
example 1
Main unit
1
Front of vehicle
Screw position
By adjusting the positions of the brackets, the
main unit's installed depth can be adjusted.
"ECLIPSE" is a registered trademark of
FUJITSU TEN LIMITED in 48 countries
- 20 -
Metal of vehicle
7 Mounting sleeve
6 Bezel
Mounting bolts
Pan screw with washer (Blue:M4 x 3).
12
Thin flat screw
(M4 x 5) x 4
Screws x 2
Mounting bracket
example 2
Main unit
1
Front of vehicle
Screw position
including the U.S. and Japan.
090003-28540700
0508DE (CN)
