System connection e
System connection e
■
AVN7000 + DCU105 + HDR105 + TVR105 + CH3083
These speaker cables are not used when
connecting an external amplifier.
If not using an external amplifier, connect the
front and rear speakers using these speaker
cables.
INTERCONNECTING CABLE
(supplied with DCU105)
1
MAIN UNIT
14
GPS ANTENNA
INTERCONNECTING CABLE
(supplied with DCU105)
Tip*1
DCU105
(sold separately)
16P
4
INTERCONNECTING
CABLE (E-lan etc)
16P
13P
DIN CABLE
(supplied with DCU105)
4P
20P
1P
16P
- 14 -
xample
xample
INTERCONNECTING CABLE
(supplied with DCU105)
INTERCONNECTING
CABLE
(supplied with DCU105)
MICROPHONE
(supplied with DCU105)
13P
13P
BEC105
(sold separately)
VIDEO
INTPUT
3 INTERCONNECTING CABLE
(Speed pulse, parking, reverse,video, etc)
2
INTERCONNECTING CABLE
(Power and speaker connector)
DIGITAL
VIDEO OUTPUT
INPUT
NAVI VOICE
OUTPUT
12P
20P
