Eclipse AVN7000 Installation Manual page 15

Tip*1
For a front 3-way speaker system
To center speaker
(with amplifier) or
external amplifier
To external amplifier
To external anplifier
To sub woofer
(with amplifier) or external amplifier
INTERCONNECTING CABLE
(supplied with HDR105)
2P
TO GROUND
TO GROUND
TV ANTENNA
(supplied with TVR105)
- Speaker connection examples -
To external amplifier
L L
CENTER
FRONT
R R
REAR SW
Hi Mid Mid Low
To external amplifier
• See DCU 105 owners manual for details.
POWER CONNECTOR
CABLE
(supplied with CH3083)
ANTENNA EXTENSION CABLE
(supplied with HDR105)
ANTENNA
PLUG
HDR105
(sold separately)
TVR105
(sold separately)
13P
13P
TO GROUND
TV ANTENNA
(supplied with TVR105)
For a front 1-way speaker system
To center speaker
(with amplifier) or
external amplifier
L
R
REAR
To external amplifier
CH3083
(sold separately)
13P
2P
TO GROUND
DIN CABLE
(supplied with CH3083)
INTERCONNECTING CABLE
(supplied with TVR105)
GROUND CABLE
12P
TO GROUND
5P
5P
6P
TO GROUND
ANTENNA SELECTOR
(supplied with TVR105)
- 15 -
To external amplifier
L
CENTER
FRONT
R
SW Hi Mid Mid Low
To sub woofer
(with amplifier) or external
amplifier
DIGITAL OUT
(Do not remove cap)
13P
INTERCONNECTING CABLE
(supplied with TVR105)
