A
NAVI-VOICE output terminal
Connect to the NAVI-VOICE input terminal of an external device such as a DCU105 (sold
separately).
B
Digital output terminal
Connect to the digital input terminal of an external device such as a DCU105 (sold separately).
C
VTR input terminals
Connect the output cable of external video equipment such as a VTR.
Yellow : Video signal
D
VTR output terminals
Connect to the monitor with video input.
Yellow : Video signal
E
Back-eye camera external input terminal (4P)
Used with the Eclipse back-eye camera (sold separately).
F
E-LAN terminal (13P)
Connect to the E-LAN terminal of the CD changer, etc.
Main unit connections
Front line-out terminal
G
Connect to the RCA connector of an external amplifier.
H
Rear line-out terminal
Connect to the RCA connector of an external amplifier.
Line-out terminal (Non fader)
I
This is used for non fader output. It can be used as a sub-woofer terminal if a separate amplifier with
a low bass filter is connected.
White : Audio (left) signal
White : Audio (left) signal
- 8 -
Red : Audio (right) signal
Red : Audio (right) signal
