Functions of the board
Example:
The incremental transmitters are programmed with reference logic in the
function modules 1 to 4. The corresponding I/O function range for the
"incremental transmitter" will be copied into the therefore allocated places
of the function modules.
The following I/O range is built:
BYTES
BASE+0
BASE +59
BASE +60 bis +63
BASE+64
BASE+ 123
BASE + 124 bis + 127
BASE+128
BASE+187
BASE +188 bis +191
BASE+192
BASE+251
BASE +252 bis +255
SC: Incremental counter
All settings on the board are realized through the software (AP), through the
connector assignment or through a reprogramming of the function module
(no jumper on the board).
54
Table 9-2: I/O range
D31...D24 D23...D16
HIGHBYTE MIDHIGHBYTE
Function module 1 - Info SCxx
Function module 2 - Info SCxx
Function module 3 - Info SCxx
Function module 4 - Info SCxx
xx: Number of version, e.g. SC23 Version 2.3
IORD / IOWR
D15.....D8
MIDLOWBYTE
Incremental counter 1
Incremental counter 1
Incremental counter 2
Incremental counter 2
Incremental counter 3
Incremental counter 3
Incremental counter 4
Incremental counter 4
APCI-1710
D7.......D0
LOWBYTE
