Addi-Data APCI-1710 Technical Description page 39

Connecting the peripheral
Table 8-3: Pin assignment for function module No. 3 (FM3)
Pin
18
19
20
21
22
23
24
25
37
41
45
49
Table 8-4: Pin assignment for function module No. 4 (FM4)
Pin
26
27
28
29
30
31
32
33
38
42
46
50
Pins with fix assignment
Pin Description
1 EXTGND
34 + UREF
Or 24 V ext.
38
Description Input/Output
A3+ Input/Output
A3- Input/Output
B3+ Input/Output
B3- Input/Output
C3+ Input
C3- Input
D3+ Input
D3- Input
H3 Digital Output
E3 Digital Input
F3 Digital Input
G3 Digital Input
Description Input/Output
A4+ Input/Output
A4- Input/Output
B4+ Input/Output
B4- Input/Output
C4+ Input
C4- Input
D4+ Input
D4- Input
H4 Digital Output
E4 Digital Input
F4 Digital Input
G4 Digital Input
Table 8-5: Special pin assignment
Input/Output
-
Output/Input
APCI-1710 APCI-1710-24 V
1
Diff. / TTL 24 V input
1
Diff. / TTL -
1
Diff. / TTL 24 V input
1
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
24 V 24 V
24 V 24 V
24 V 24 V
24 V 24 V
ACPI-1710 APCI-1710-24 V
1
Diff. / TTL 24 V input
1
Diff. / TTL -
1
Diff. / TTL 24 V input
1
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
24 V 24 V
24 V 24 V
24 V 24 V
24 V 24 V
Function
Reference potential
- voltage output for TTL
signals or
- 24 V supply for 24 V
outputs
APCI-1710
Note
For all inputs and
outputs
Configurable
through ST3
