- Page 1 DIN EN ISO 9001:2000 certified ADDI-DATA GmbH Dieselstraße 3 D-77833 OTTERSWEIER Technical support: +49 (0)7223 / 9493 – 0 Technical description ADDIALOG APCI-3504 Analog output board for the PCI bus edition 06/2005...
- Page 2 The user is not permitted to make changes to the product beyond the intended use, or to interfere with the product in any other way. ADDI-DATA shall not be liable for obvious printing and phrasing errors. In addition, ADDI DATA, if legally permissible, shall not be liable for personal injury or damage to materials caused by improper...
- Page 3 WARNUNG In case of wrong uses and if the board is not used for the purpose it is intended: ♦ people may be injured, ♦ the board, PC and peripheral may be destroyed, ♦ the environment may be polluted ♦ Protect yourself, the others and the environment! ♦...
-
Page 4: Table Of Contents
Contents APCI-3504 INTENDED PURPOSE OF THE BOARD...... 7 Limits of use..............8 USER ..............9 Qualification ..............9 Personal protection............9 HANDLING OF THE BOARD ........10 TECHNICAL DATA..........11 Elektromagnetic compatibility (EMC)......11 Physical set-up of the board ..........11 Versions ................12 Limit values..............12 4.4.1 Voltage outputs .............. - Page 5 Contents APCI-3504 7.2.3 Screw terminal and connector assignment ......26 Connector assignment (Board and srew terminal board) ...26 Screw terminal assigment............27 FUNCTIONS OF THE BOARD ........ 28 Block diagram..............28 Analog outputs ...............28 8.2.1 Voltage outputs ..............29 8.2.2 Current outputs..............30 Watchdog...............30 Timer................30 STANDARD SOFTWARE ........
- Page 6 Contents APCI-3504 Figures Fig. 3-1: Correct handling ..............10 Fig. 4-1: Component scheme ............14 Fig. 4-2: Component scheme (solder side) ........15 Fig. 5-1: PCI-5V slot (32-bit)............... 16 Fig. 5-2: Opening the blister pack............ 16 Fig. 5-3: Inserting the board ............. 17 Fig.
-
Page 7: Intended Purpose Of The Board
APCI-3504 Intended purpose of the board INTENDED PURPOSE OF THE BOARD The board APCI-3504 is the interface between an industrial process and a personal computer (PC). The board APCI-3504 must be inserted in a PC with PCI 5V/32-bit slots, which is used as electrical equipment for measurement, control and laboratory use as definedn in the norm IEC 61010-1. -
Page 8: Limits Of Use
Intended purpose of the board APCI-3504 Limits of use The use of the board in a PC could change the PC features regarding noise emission and immunity. Increased noise emission or decreased noise immunity could result in the system not being conform anymore. The APCI-3504 board is not to be used as safety related part for securing emergency stop functions. -
Page 9: User
APCI-3504 User USER Qualification Only persons trained in electronics are entitled to perform the following works: installation use, maintenance. Personal protection Consider the country-specific regulations about: the prevention of accidents electrical and mechanical installations radio interference suppression. -
Page 10: Handling Of The Board
Handling of the board APCI-3504 HANDLING OF THE BOARD Fig. 3-1: Correct handling... -
Page 11: Technical Data
APCI-3504 Technical data TECHNICAL DATA Elektromagnetic compatibility (EMC) The board has been subjected to EMC tests in an accredited laboratory. The board complies with the limit values set by the norm EN55011 and EN61000-6-2 as follows: True value Set value ESD (Discharge by contact/air) .... -
Page 12: Versions
Technical data APCI-3504 Versions 2 versions of the board APCI-3504 are availabe. APCI-3504 APCI-3504-C Analog outputs 4 voltage outputs 4 current outputs Limit values Max. altitude: ..........2000 m Operating temperature: ......0 to 60°C Storage temperature: ......... -25 to 70°C Relative humidity: ........ -
Page 13: Current Outputs (Apci-3504-C)
APCI-3504 Technical data 4.4.2 Current outputs (APCI-3504-C) Number of channels: ......... 4 analog outputs Resolution: ..........12-bit Max output current: ........0 to 20 mA LSB: ............4.883 µA Typical error: ..........≤ 25 µA Max. error: ..........≤ 100 µA Time to ready (tr): ........ -
Page 14: Component Scheme
Technical data APCI-3504 Component scheme Fig. 4-1: Component scheme... -
Page 15: Fig. 4-2: Component Scheme (Solder Side)
APCI-3504 Technical data Fig. 4-2: Component scheme (solder side) -
Page 16: Installation Of The Board
Installation of the board APCI-3504 INSTALLATION OF THE BOARD IMPORTANT! Do observe the safety precautions (yellow leaflet)! Opening the PC ♦ Switch off your PC and all the units connected to the PC ♦ Pull the PC mains plug from the socket. ♦... -
Page 17: Plugging The Board Into The Slot
APCI-3504 Installation of the board Plugging the board into the slot ♦ Insert the board vertically into the chosen slot. Fig. 5-3: Inserting the board ♦ Fasten the board to the rear of the PC housing with the screw which was fixed on the back cover. -
Page 18: Software
ADDI-DATA software is based on the principle of a virtual board: it transposes the different functions (e.g. digital inputs, analog outputs, timer, ...) of all inserted ADDI-DATA boards as the functions of a single (virtual) board. The virtual board features a pool of functions, the functionality of which can be called up without calling a specific board. -
Page 19: Board Registration
APCI-3504 Software Board registration When starting the set-up of ADDIREG, the APCI-3504 is automatically recognised and registered. 6.1.1 Installation of a new board If a new board is recognised, the following windows is displayed: Fig. 6-1: New inserted board (Example) The boards which have been removed from the PC since the last ADDIREG start are listed in the upper table The new inserted boards are listed in the lower table. -
Page 20: Addevice Manager
Software APCI-3504 ADDevice Manager Fig. 6-2: ADDevice Manager (Example) The following parameters are displayed for every inserted board: First column: Board name Board index: Number allocated to the board when it is registered in ADDIREG. Slot number IRQ line Different addresses which are automatically allocated to the board by the BIOS. -
Page 21: Changing The Registration Of A Board
APCI-3504 Software By clicking twice within a column, the connection principle and the technical data of the resource are displayed. This function is only possible if a question mark appears with the cursor. You can export the set configuration as a text file. Click on "file" and save the configuration as a .txt file with "Export information to file...". - Page 22 Selected base address of the board. For PCI boards the base address is allocated through BIOS. Access: Selection of the access mode for the ADDI-DATA digital boards. Access in 8-bit or 16-bit or 32-bit mode. PCI bus/device/(slot): Number of the used PCI bus, slot, and device. If the board is no PCI board, the message "NO"...
- Page 23 APCI-3504 Software Buttons: Edit: Selection of the highlighted board with the different parameters set in the text boxes. Set: Sets the parametered board configuration. The configuration should be set before you save it. Cancel: Reactivates the former parameters of the saved configuration. Default: Sets the standard parameters of the board.
-
Page 24: Registration Test
ADDIREG program and directly begin with your application. Questions and software downloads on the web Do not hesitate to e-mail us your questions. per e-mail: info@addi-data.de hotline@addi-data.de Free downloads of standard software You can download the latest version of the software for the APCI-3504 http://www.addi-data.de... -
Page 25: Connecting The Peripheral
APCI-3504 Connecting the peripheral CONNECTING THE PERIPHERAL Connector pin assignment Fig. 7-1: 15-pin. SUB-D female connector (BU1) Connection to the screw terminal board PX 9200 7.2.1 Connection of the APCI-3504 to the PX 9200 Fig. 7-2: Connection to the screw terminal board PX 9200... -
Page 26: Layout Of The Screw Terminal Board
Connecting the peripheral APCI-3504 7.2.2 Layout of the screw terminal board Fig. 7-3: Layout of the screw terminal board PX 9200 7.2.3 Screw terminal and connector assignment The assignment of the front connector BU1 of the board is identical to the assignment of the connector BU1 of the screw terminal board. -
Page 27: Screw Terminal Assigment
APCI-3504 Connecting the peripheral Screw terminal assigment Fig. 7-4: Terminal assignment of the PX 9200... -
Page 28: Functions Of The Board
Functions of the board APCI-3504 FUNCTIONS OF THE BOARD Block diagram Fig. 8-1: Block diagram of the APCI-3504 Analog outputs There are 4 analog output channels with 12-bit resolution on the board. The analog outputs are updated through 32-bit write operations on I/O addresses. -
Page 29: Voltage Outputs
APCI-3504 Functions of the board Fig. 8-2: Reaction time of the analog outputs 8.2.1 Voltage outputs The analog output channels are set to a 0 V voltage value after Power-ON Reset of the PC. Fig. 8-3: Switching principle of the analog ground lines (Voltage version) -
Page 30: Current Outputs
Functions of the board APCI-3504 8.2.2 Current outputs The analog output channels are set to a 0 mA current value after Power-ON Reset of the PC. Fig. 8-4: Switching principle of the analog ground lines (current version) Watchdog A 12-bit watchdog is available on the APCI-3504 which resets the analog outputs after running down of its reload value (timeout). -
Page 31: Standard Software
APCI-3504 Standard software STANDARD SOFTWARE Software functions ADDIPACK supports the following functions for the APCI-3504. Table 9-1: Supported software functions Functionality Function name Global i_ADDIDATA_OpenWin32Driver i_ADDIDATA_GetCurrentDriverHandle functions i_ADDIDATA_GetDriverVersion b_ADDIDATA_CloseWin32Driver b_ADDIDATA_SetFunctionalityIntRoutineWin32 Interrupt b_ADDIDATA_TestInterrupt b_ADDIDATA_ResetFunctionalityIntRoutine Error i_ADDIDATA_GetLastError b_ADDIDATA_EnableErrorMessage b_ADDIDATA_DisableErrorMessage b_ADDIDATA_FormatErrorMessage (...) Timer b_ADDIDATA_GetNumberOfTimers b_ADDIDATA_GetTimerInformation b_ADDIDATA_InitTimer... - Page 32 Standard software APCI-3504 b_ADDIDATA_GetNumberOfWatchdogs Watchdog b_ADDIDATA_GetWatchdogInformation b_ADDIDATA_GetWatchdogInformationEx b_ADDIDATA_InitWatchdog b_DelayTimeUnit 1: µs 2: ms 3: s dw_DelayValue Min 0, Max 4095 b_ADDIDATA_EnableDisableWatchdogInterrupt b_ADDIDATA_StartWatchdog b_ADDIDATA_StopWatchdog b_ADDIDATA_ReadWatchdogStatus b_ADDIDATA_ReleaseWatchdog Analog b_ADDIDATA_GetNumberOfAnalogOutputs b_ADDIDATA_GetAnalogOutputInformation outputs b_ADDIDATA_Init1AnalogOutput b_VoltageMode Min 0 (Bipolar -+10V) Max 1 (Unipolar 0-10V) b_Polarity 2 Bipolar (Only with b_VoltageMode Mode 0) 1 Unipolar (Only with b_VoltageMode Mode 1) b_ADDIDATA_InitMoreAnalogOutputs...
-
Page 33: Software Samples
APCI-3504 Standard software Software samples Table 9-2: Supported software samples for the APCI-3504 Functionality Sample Description number Analog SAMPLE01 Write 1 analog output value without synchronising. outputs SAMPLE02 Write several analog output values without synchronising. Timer SAMPLE01 Initialise 1 timer in mode2 without interrupt SAMPLE02 Initialise 1 timer in mode2 with interrupt SAMPLE01...
