Technical data
4.3

Versions

The board APCI-1710 is available in the following two versions:
Version
APCI-1710
APCI-1710-24V
4.4

Limit values

Max. altitude: ............................................ 2000 m
Operating temperature: .............................. 0 to 60°C
Storage temperature: ................................. -25 to 70°C
Relative humidity at indoor installation
50% at +40 °C
80% at +31 °C
Minimum PC requirements:
PCI BIOS from Version 1.0
Bus speed: ................................................. < 33 MHz
Data bus access: .........................................32-bit
Decoding: ...................................................in the 64 K I/O area of the PC
"Target Only" operation
Operating system: ..................................... Windows NT 4.0, 9x, 2000,
Resources
I/O area
3 areas: .......................................................64 bytes,
IRQs: ..........................................................INTA of the PCI bus
Energy requirements:
Operating voltage of the PC: ..................... 5 V ± 5%
Current consumption (without load): ........if + 5 V from PC: 1.15 A (±10 %)
....................................................................(for standard version APCI-1710)
14
Format Onboard
function
modules
PCI 4
PCI 4
Linux
8 bytes,
256 bytes
if + 24 V ext:
APCI-1710
Options
5 V inputs (mass-related)
Digital 5 V outputs
-
10 mA (±10 %)
