Available functions of the APCI-1710

5 AVAILABLE FUNCTIONS OF THE APCI-1710
5.1

Available signals

5.1.1 Connectable signal lines

The lines are divided according to the board as follows:
Input lines:
2 x TTL, RS422 (signals C, D)
-
3 x 24 V, 5 V optional (signals E, F, G)
-
Output lines:
- 1 x 24 V, TTL optional (signal H)
Free definable lines (input or output):
2 x TTL, RS422 (signals A, B)
-
24 V version (APCI-1710-24V):
7 x 24 V inputs (signals A to G)
-
1 x 14 V output, TTL optional (signal H)
-

5.1.2 Maximal signal wirings of the APCI-1710

Table 5-1: Maximal input lines on the board

28
of them are
- 16 differential inputs and
- 12 x 24 V inputs

Table 5-2: Maximal input lines on a module

7
of them are
- 4 differential
- 3 x 24 V inputs

Table 5-3: Maximal output lines on the board

12
Of them are
- 8 differential outputs and
- 4 x 24 V outputs
20
Inputs
Inputs
Outputs
Available outputs
4 (H)
Available outputs
1
Available inputs
20
Of them are
8 differential
12 x 24 V inputs (E,F,G)
APCI-1710
