- Page 1 ADDI-DATA GmbH Dieselstraße 3 D-77833 OTTERSWEIER +49 (0)7223 / 9493 – 0 Technical description ADDINUM PA 200 Digital output board edition 10/2004...
- Page 2 The user is not permitted to make changes to the product beyond the intended use, or to interfere with the product in any other way. ADDI-DATA shall not be liable for obvious printing and phrasing errors. In addition, ADDI DATA, if legally permissible, shall not be liable for personal injury or damage to materials caused by improper...
- Page 3 WARNING The following risks result from improper implementation and from use of the board contrary to the regulations: ♦ Personal injury ♦ Damage to the MSX-Box, PC and peripherals ♦ Pollution of the environment ♦ Protect yourself, the others and the environment! ♦...
-
Page 4: Table Of Contents
Contents PA 200 DEFINITION OF APPLICATION ........6 Intended use ................6 Usage restrictions..............6 General description of the board ..........6 USER ................7 Qualification ................7 Personal protection..............7 HANDLING OF THE BOARD........... 8 TECHNICAL DATA ............9 Electromagnetic compatibility (EMC) ........9 Physical set-up of the board ............9 Limit values................10 Component scheme...............11 SETTINGS OF THE BOARDS ......... - Page 5 PA 200 Contents FUNCTIONS OF THE BOARD ........24 Introduction ................24 Programming .................24 Programming examples in C, Pascal, Assembler, Basic..25 Figures Fig. 3-1: Correct handling ................8 Fig. 4-1: Component scheme ..............11 Fig. 5-1: Block of DIP switches S1 .............. 13 Fig.
-
Page 6: Definition Of Application
Definition of Application PA 200 DEFINITION OF APPLICATION Intended use The board PA 200 must be inserted in a PC with ISA slots, which is used as electrical equipment for measurement, control and laboratory pursuant to the norm IEC 61010-1. Usage restrictions The PA 200 board must not to be used as safety related part for securing emergency stop functions. -
Page 7: User
PA 200 User USER Qualification Only persons trained in electronics are entitled to perform the following works: installation use, maintenance. Personal protection Consider the country-specific regulations about: the prevention of accidents electrical and mechanical installations radio interference suppression. -
Page 8: Handling Of The Board
Handling of the board PA 200 HANDLING OF THE BOARD Fig. 3-1: Correct handling... -
Page 9: Technical Data
PA 200 Technical data TECHNICAL DATA Electromagnetic compatibility (EMC) The PC is to comply with the norm IEC61326 for measurement, control and laboratory use and with the specifications for EMC protection. The board has been subjected to EMC tests in an accredited laboratory. The board complies with the limit values set by the norms IEC61326 as follows: True value Set value... -
Page 10: Limit Values
Technical data PA 200 Limit values Max. altitude: ..........2000 m Operating temperature: ......0 to 60°C Storage temperature: ......... -25 to 70°C Relative humidity: ........30% to 99% non condensing Minimum PC requirements: PCI BIOS from Version 1.0 ISA bus interface: ........8 MHz Operating system: ........ -
Page 11: Component Scheme
PA 200 Technical data Component scheme Fig. 4-1: Component scheme... -
Page 12: Settings Of The Boards
Settings of the boards PA 200 SETTINGS OF THE BOARDS IMPORTANT! Do observe the safety precautions (yellow leaflet)! Setting the base address through DIP switches WARNING! If the base address set is wrong, the board and/or the PC may be destroyed At delivery the base address is set to 0390H. -
Page 13: Decoding The Base Address
PA 200 Settings of the boards 5.1.3 Decoding the base address J4 * J3 * J2 * J1 * Switch Address A15 A14 A13 A12 A11 A10 Table 5-1 the address 0390H is decoded. (Settings at delivery). The adjustment of the board occurs over a block of 10 DIP switches. The switches designated S1 to S10 can be switched "ON"... -
Page 14: Installation Of The Board
Installation of the board PA 200 INSTALLATION OF THE BOARD IMPORTANT! Do observe the safety precautions (yellow leaflet)! Opening the PC ♦ Switch off your PC and all the units connected to the PC ♦ Pull the PC mains plug from the socket. ♦... -
Page 15: Plugging The Board Into The Slot
PA 200 Installation of the board Plugging the board into the slot ♦ Insert the board vertically into the chosen slot. Fig. 6-3: Inserting the board ♦ Fasten the board to the rear of the PC housing with the screw which was fixed on the back cover. -
Page 16: Software
The ADDIREG registration program is a 32-bit program for Windows NT XP/2000/NT 4.0/ 9x. The user can register all hardware information necessary to operate the ADDI-DATA PC boards. IMPORTANT! If you use one or several resources of the board, you cannot start the ADDIREG program. -
Page 17: Fig. 7-1: Addireg Registration Program (Example)
The base address set in ADDIREG must correspond to the one set through DIP switches. Access: Selection of the access mode for the ADDI-DATA digital boards. Access in 8-bit or 16-bit or 32-bit mode. PCI bus/device/(slot): Number of the used PCI bus, slot, and device. If the board is no PCI board, the message "NO"... - Page 18 Software PA 200 DMA (ISA boards only): Indicates the selected DMA channel or "Not available" if the board uses no DMA or if the board is no ISA board. More information: Additional information like the identifier string or the installed COM interfaces. It also displays whether the board is programmed with ADDIDRIVER or if a PCI DMA memory is allocated to the board.
-
Page 19: Registering A New Board
PA 200 Software ADDIDriver Board Manager (only for the boards with ADDIPACK): Under Edit/ADDIDriver Board Manager you can check or change the current settings of the board set through the ADDEVICE Manager. ADDevice Manager starts and displays a list of all resources available for the virtual board. -
Page 20: Changing The Registration Of A Board
Software PA 200 You can test if the registration is "OK". This test controls if the registration is right and if the board is present. If the test has been successfully completed you can quit the ADDIREG program. The board is initialised with the set parameters and can now be operated. In case the registration data is to be modified, it is necessary to boot your PC again. -
Page 21: Connecting The Peripheral
PA 200 Connecting the peripheral CONNECTING THE PERIPHERAL Connector pin assignment Fig. 8-1: 37-pin SUB-D male connector... -
Page 22: Connection Examples
Connecting the peripheral PA 200 Connection examples Fig. 8-2: Connection examples... -
Page 23: Connection To The Screw Terminal Boards
PA 200 Connecting the peripheral Connection to the screw terminal boards Fig. 8-3: Connection to the screw terminal board PX 901Functions of the board... -
Page 24: Functions Of The Board
Functions of the board PA 200 FUNCTIONS OF THE BOARD Introduction The PA 200 requires no initialization. It can be used immediately after power has been turned on and after successful reset of the CPU. The address decoding relates to the 64 KB I/O address area. Both lower address bits are decoded for selecting 4 blocks of 8 outputs. -
Page 25: Programming Examples In C, Pascal, Assembler, Basic
PA 200 Functions of the board Programming examples in C, Pascal, Assembler, Basic /* TURBO C /* Writes digital outputs of a PA200 board /* Used compiler: TURBO C version 2.0 mode SMALL #define Basic_Adr_PA200 0x390 /* Basic address of PA200 board*/ void main (void) ***** Main program ***** */... - Page 26 Functions of the board PA 200 ; TASM ; Writes digital outputs of a PA200 board ; Used compiler: TASM version 1.0 mode SMALL Basic_Address_PA200 = 390h ; Basic address of PA200 board DOSSEG .MODEL SMALL .STACK 100h .DATA .CODE AX,@DATA DS,AX ;...
