Addi-Data APCI-1710 Technical Description page 38

APCI-1710
WARNING!
Pin 34 of the front connector has a double assignment function.
If you do not connect Pin 34 correctly, your board can be
destroyed.
The following tables show the pin assignment of the digital inputs and
outputs and the respecting signals and functions.
The inputs and outputs shall be switched on the module after the
programming of the function (direction change-over depends on the selected
function).
Table 8-1: Pin assignment for function module No. 1 (FM1)
Pin
2
3
4
5
6
7
8
9
35
39
43
47
Table 8-2: Pin assignment for function module No. 2 (FM2)
Pin Description
10
11
12
13
14
15
16
17
36
40
44
48
1
On the 24 V signals (APCI-1710-24 V) only inputs can be connected
2
Ax-, Bx-, Cx-, Dx- pins do not have a function on the 24 V board (see Fig. 9-5)
Description Input/Output
A1+ Input/Output
A1- Input/Output
B1+ Input/Output
B1- Input/Output
C1+ Input
C1- Input
D1+ Input
D1- Input
H1 Digital Output
E1 Digital Input
F1 Digital Input
G1 Digital Input
Input/Output
A2+ Input/Output
A2- Input/Output
B2+ Input/Output
B2- Input/Output
C2+ Input
C2- Input
D2+ Input
D2- Input
H2 Digital Output
E2 Digital Input
F2 Digital Input
G2 Digital Input
Connecting the peripheral
APCI-1710 APCI-1710-24 V
Diff. / TTL 24 V input
1
1
Diff. / TTL -
2
1
Diff. / TTL 24 V input
1
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
24 V 24 V
24 V 24 V
24 V 24 V
24 V 24 V
APCI-1710 APCI-1710-24 V
1
Diff. / TTL 24 V input
1
Diff. / TTL -
1
Diff. / TTL 24 V input
1
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
Diff. / TTL 24 V
Diff. / TTL -
24 V 24 V
24 V 24 V
24 V 24 V
24 V 24 V
37
