Connecting the peripheral
47 I2
48 J2
49 I1
50 J1
1
PA, PB and PC : Pullup on 5 V
2
Serial resistance 100 Ω, PD
PA, PB, PC and PD can be used through the function module "TTL I/O".
8.2 Connection of mass-related inputs and
outputs

Fig. 8-5: Connection of a mass-related input

42
2
TTL, input or output; after reset: output, FM2
2
TTL, input or output; after reset: output, FM2
2
TTL, input or output; after reset: output, FM1
2
TTL, input or output; after reset: output, FM1
APCI-1710
49
33
17
50
