RJ45 Define
Video Link (TIA/EIA-568-B)
1. Orange-white DATA0 +
2. Orange DATA0 -
3. Green-white DATA1 +
4. Blue DATA2 +
5. Blue-white DATA2 -
6. Green DATA1 -
7. Brown-white DATA3 +
8. Brown DATA3 –
Caution
1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone,
microwave, radio equipment, fluorescent lamp, high voltage power lines.
2. The cable must pull in straight to avoid any crosstalk interference and the transmission stability.
3. This device HDBaseT port is not general Ethernet signal; do not connect with Network devices to
avoid damage.
4. IR transmitter do not put near from receiver to avoid mutual interference.
5. The receiver unit working temperature is higher which is in normal condition.
HE02EIP Package Include
HE02EIPT HDM Transmitter x 1 pcs
HE02EIPR HDMI Receiver x 1 pcs
IR Emitter Cable x 2 pcs
IR Receiver Cable x 2 pcs
Mounting Screw pack x 1 bags
DC12V 1Amp Power Adapter x 1 pcs
