13.7 AIS OPERATION

The GX2150 is equipped with an AIS ( A
and can display AIS targets around your vessel on the radios display. There-
fore, you can identify and avoid other large vessels nearby your vessel.
The GX2000 can also show AIS targets, however a separate AIS receiver or
transponder with NMEA VDM 34800 baud must be connected to the acces-
sory cable.
To show AIS targets on radios display, a GPS needs to be connected so
the radio knows it position relative to the AIS targets.
1. Press the
AIS display shows your vessel as a triangle in the
center of the display. AIS targets are shown as
circles. The line projected from the circle is the AIS
vessels course over ground (COG).
2. Press the one of the soft keys momentarily, then
press the
sels being received.
Note: Up to 10 AIS targets can be shown on the
display.
3. Rotate the CHANNEL knob to select the MMSI num-
ber (or vessel name). The selected AIS target is dis-
played with " " icon, other station is displayed with
" " icon.
4. Press the one of the soft key momentarily, then press the
show more information of the AIS target.
Note: When the "LIST" and "INFO" pages are shown, the radio will update
every ten seconds, so it may take some time to show the vessels names
instead of the MMSI and update the navigation information of each ship.
The AIS output of the GX2150 is updated in realtime as transmissions are
received from the AIS equipped ships.
5. To see AIS information of another AIS target, press the
peat presses of the
Page 100
NOTE
key to show the AIS screen. The
soft key to show a list of AIS ves-
key will scroll though all the AIS Targets.
I
UTOMATIC
DENTIFICATION
) receiver
S
YSTEM
key to
key. Re-
