Advantech PCIE-1730H-AE User Manual

Advantech PCIE-1730H-AE User Manual

32-ch isolated digital i/o with digital filter pci express card

Advertisement

Quick Links

User Manual
PCIE-1730/1730H
32-Ch Isolated Digital I/O with
Digital Filter PCI Express Card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIE-1730H-AE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech PCIE-1730H-AE

  • Page 1 User Manual PCIE-1730/1730H 32-Ch Isolated Digital I/O with Digital Filter PCI Express Card...
  • Page 2 The documentation and the software included with this product are copyrighted 2020 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 We recommend the use of shielded cables. This type of cable is available from Advantech. Test conditions for passing include the equipment being operated within an industrial enclosure. In order to protect the prod-...
  • Page 4 Document Feedback To assist us with improving this manual, we welcome all comments and constructive criticism. Please send all feedback in writing to support@advantech.com Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.
  • Page 5 In accordance with IEC 704-1:1982 specifications, the sound pressure level at the operator's position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided in accordance with the IEC 704-1 specifications. Advantech disclaims all responsibility for the accuracy of any state- ments contained herein. PCIE-1730/1730H User Manual...
  • Page 6 PCIE-1730/1730H User Manual...
  • Page 7: Table Of Contents

    Contents Chapter Overview..........1 Introduction ....................2 Features ....................2 Software Overview ..................3 Accessories....................3 Installation Guide ..................4 Product Applications ................. 4 Chapter Hardware Installation ......5 Unpacking Instructions................6 Driver Installation ..................7 Hardware Installation ................7 Figure 2.1 Device Manager ............8 Chapter Signal Connections ......9...
  • Page 8 PCIE-1730/1730H User Manual viii...
  • Page 9: Chapter 1 Overview

    Chapter Overview...
  • Page 10: Introduction

    Introduction Advantech’s PCIE-1730 series are 32-channel isolated digital I/O cards that support PCI Express bus. The provision of isolated digital input channels make these cards ideal for environments with noise or floating potentials. The following sections of this chapter provide information regarding the features, installation process, and relevant software and accessories for the PCIE-1730 series cards.
  • Page 11: Software Overview

    Wiring Boards Advantech’s ADAM-3937 is a 37-pin D-type wiring terminal module for DIN-rail mounting. This terminal module can be connected to Advantech DAQ cards and pro- vides easy access to individual pin connections for the PCIE-1730 series. The PCLD-880 is a universal screw terminal board that can be integrated with any Advantech DAQ card that features a 37-pin D-type connector.
  • Page 12: Installation Guide

    1 x PCIE-1730 series card  1 x PCIE-1730 series user manual  1 x Advantech DAQNavi driver (included in the CD-ROM)  1 x Personal computer or workstation with a PCI-Express slot  Additional optional components are available for enhanced operation.
  • Page 13: Chapter 2 Hardware Installation

    Chapter Hardware Installation...
  • Page 14: Unpacking Instructions

    After retrieving the card, first inspect the card for any external signs of damage (loose or damaged components etc.). If the card is visibly damaged, please notify the Advantech service department or your local sales representative immediately. Do not install a damaged card in your system.
  • Page 15: Driver Installation

    Driver Installation To ensure problem-free installation, all relevant drivers should be installed before installing the PCIE-1730 series card. The Advantech device drivers for the PCIE- 1730 series card are provided on the accompanying CD-ROM shipped with your product. Hardware Installation...
  • Page 16 Manager list by clicking on the device and selecting the Remove option. Then perform the device installation process again. After the Advantech DAQNavi driver and PCIE-1730 series card are properly installed, users can configure the system using the Advantech Navigator Utility.
  • Page 17: Chapter 3 Signal Connections

    Chapter Signal Connections...
  • Page 18: Overview

    Overview Maintaining signal connections is crucial for ensuring applications are sending and receiving data correctly. Good signal connections can prevent unnecessary and costly data losses and hardware damage. This chapter provides information that explains how to connect input and output signals to the PCIE-1730 series card via the I/O connector.
  • Page 19: Signal Connections

    Signal Connections PCIE-1730 Series Pin Assignments IDO 0 1 IDO 1 IDI 0 IDI 1 IDO 2 3 IDO 3 IDI 2 IDI 3 IDO 4 5 IDO 5 IDI 4 IDI 5 IDO 6 7 IDO 7 IDI 6 IDI 7 IDO 8 9 IDO 9...
  • Page 20 TTL-Level Digital Input/Output The PCIE-1730 series cards have 16 TTL-level digital inputs and 16 TTL-level digital outputs. The connection configuration for exchange digital signals with other TTL devices is shown in Figure 3.2. Figure 3.2 TTL-Level DI/O Connection The connection configuration for receiving an OPEN/SHORT signal from a switch or relay is shown in Figure 3.3.
  • Page 21 Isolated Digital Input Each isolated digital input channel accepts bi-directional 10~30V voltage inputs means that user can apply positive or negative voltage to any input pin. Every eight input channels share one external common. (Channels 0 ~ 7 use ECOM0. Channels 8 ~ 15 use ECOM1.) Figure 3.4 shows how to connect an external input source to the card's isolated inputs.
  • Page 22 PCIE-1730/1730H User Manual...
  • Page 23: Appendix A Specifications

    Appendix Specifications...
  • Page 24: Specifications

    Specifications A.1.1 Isolated Digital Input Input Channels Logic 0: 3 V max. (0 V min.) Input Voltage Logic 1: 10 V min. (30 V max.) 12 V @ 3.18 mA Input Current 24 V @ 6.71 mA Interrupt-Capable 2 for PCIE-1730, 16 for PCIE-1730H Channel Digital Filter Channel 16 (for PCIE-1730H only)
  • Page 25: General

    A.1.4 General I/O Connector Type 37-pin D-sub female Dimensions 175 x 100 mm (6.9 x 3.9 in) +3.3 V @ 280 mA Typical +12 V @ 330 mA Power Consumption +3.3 V @ 420 mA Max. +12V @ 400 mA Operating 0 ~ 60 °C (32 ~ 140 °F) (refer to IEC 68-2-1, 2) Temperature...
  • Page 26 PCIE-1730/1730H User Manual...
  • Page 27: Appendix B Block Diagram

    Appendix Block Diagram...
  • Page 28: Pcie-1730 Series Diagram

    PCIE-1730 Series Diagram PCIE-1730/1730H User Manual...
  • Page 29 PCIE-1730/1730H User Manual...
  • Page 30 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2020...
