Adjusting the Camera angle
Adjusting the camera angle
Adjust the camera angle while the camera is fixed on the ceiling.
Loosen the pan and tilt screw at the base of the camera a little before moving the
camera module.
Pan is used to rotate the camera's body to left and right, and tilt is used to adjust the
tilt. Rotating the lens by its axis is called rotation.
- Panning: 360°
- Rotation: 360°
- Tilting: 90°
Panning 360°
Tilting 90°
14
Rotation 360°
