OSD Menu Color
_
WB MODE
COLOR
EXPO RGB D&N
WHITE BAL.

COLOR GAIN

EXIT JUMP
AUTO
Auto Tracking White Balance Control mode compensates for color temperature changes
between 2500K ˚ and 12000K ˚.
AUTO-EX Auto White Balance Control mode compensates for color temperature changes lower than
2500K ˚ and tigher than 12000K ˚.
PRESET Preset xes the white balance based on the current lighting automatically.
MANUAL Users can control the white balance manually by changing RED GAIN and BLUE GAIN. (see blow)
C-TEMP: Select the color temperature for the white balance setup. If enabled,
the Red and Blue Gain settings will be set automatically according to the C-TEMP selected.
RED GAIN: 0 ~ 20. Adjusts the amount of red in the image.
BLUE GAIN: 0 ~ 20. Adjust the amount of blue in the image.
COLOR GAIN Set the color gain from 0~20.
FUNC MOTI PRIV SET EXIT
AUTO
10
20
WHITE BAL.
C-TEMP 5000K
R-GAIN 10
B-GAIN 10
RETURN
