Connecting to DVR/Encoder (UTP)
Use the diagram below to connect to a Universal DVR or Monitor properly.
12VDC/24VAC
Monitor
- Power Connection : 12VDC/24VAC Dual Voltage. (Auto Polarity Detection and Protection)
- All cameras are equipped with a test video output for on-site con guration.
Note : When switching to UTP/Coax switch to UTP, the image will not be output when switched to Coax.
UTP
Balun
(Receiver at DVR side)
Test Video Output
UTP/Coax switch
UTP
13
UNIVERSAL DVR
COAX
