Introduction
This document applies to revision 2.0 SPEAr320 CPU evaluation boards.
This board can be used to evaluate SPEAr320 microprocessors; the evaluation board kit
comprises one board, one serial cable interface, and one power supply.
CPU board features
■ SPEAr320 embedded MPU
■
Up to 2 Gbit DDR2 333 MHz (standard 128 Mbytes)
■
Up to 16 Mbyte Serial Flash memory (standard 8 Mbytes)
■
Two USB 2.0 full host port channels
■
One USB 2.0 host device port
■
One serial port (up to 115 baud)
■
JTAG Debug ports
SPEAr320 CPU evaluation board
Top
SPEAr320 CPU evaluation board
