User Manual of Thermal Bi-spectrum Network Speed dome
Normal Mode: Set the DNR level from 0~ 100, and the default value is 50.
Expert Mode: Set the DNR level from both space DNR level [0~100] and time DNR level
[0~100] in Expert Mode.

Palettes
The palettes allow you to select the desired colors. white hot, black hot, fusion 1, rainbow,
fusion 2, ironbow 1, ironbow2, sepia, color 1, color 2, ice fire, rain, red hot, and green hot
are selectable.

DDE
The DDE (Digital Detail Enhancement) can adjust the details of the image. And you can set it
to OFF or Normal mode. And DDE Level can be adjust from 1 to 100 when in normal mode.

Brightness Sudden Change Suppression
When the brightness of target and the background is hugely different (the temperat
ure difference of target and background is huge), the system reduces the difference
for viewing.
 Video Adjustment

Mirror
If you turn the Mirror function on, the image will be flipped. You can set the
mirror direction to Center or disable it.
This function varies depending on the models of speed dome.

Video Standard
The Video Standard is configurable.
This function varies depending on the models of speed dome.

Capture Mode:
You can set the Capture Mode to OFF and 384*288@25fps.

Digital Zoom
The digital zoom is available for the thermal sensor, there are x2 and X4 selectable.
This function varies depending on the models of speed dome.

7.4.2 Configuring OSD Settings

Purpose:
The speed dome supports following on screen displays:
Time: Supports for time display.
