Control Throws - Seagull Models T-34C MENTOR Assembly Manual

T-34 MENTOR
With the wing attached to the fuselage,
all parts of the model installed ( ready to
fly), and empty fuel tanks, hold the mod-
el at the marked balance point with the
stabilizer level.
Lift the model. If the tail drops when
you lift, the model is "tail heavy" and you
must add weight* to the nose. If the nose
drops, it is "nose heavy" and you must
add weight* to the tail to balance.
*If possible, first attempt to balance the
model by changing the position of the re-
ceiver battery and receiver. If you are un-
able to obtain good balance by doing so,
then it will be necessary to add weight to
the nose or tail to achieve the
proper balance point.
32
Instruction Manual.
120mm

CONTROL THROWS.

Ailerons:
High Rate : 15mm
Low Rate : 12mm
Elevator:
High Rate : 15mm
Low Rate : 12 mm
Rudder:
High Rate : 25mm
Low Rate : 20 mm
