Partition Partition
Number Letter
1 H:
2 I:
3 J:
None None
None None
flashcopy backup
80
IBM ServeRAID-3H, ServeRAID-3HB, and ServeRAID-3L, Controllers
controller is the ServeRAID controller number (1–12)
For example, if you type ipssend flashcopy 2 map, the following results
appear on the screen:
Found 2 IBM ServeRAID Controller(s).
Partition Logical
Size Drive
100 1
100 2
50 2
- 3
- 4
Note 1:
This partition is currently in an active FlashCopy link. See the table
below for details. Use the STOP command to break this link. Once the
link is broken, you can reissue the FLASHCOPY BACKUP or FLASHCOPY
NOBACKUP command.
Note 5:
There is no partition defined on this logical drive.
If a partition is available for FlashCopy, the report states Yes and there are no
notes for that partition. If a partition is not available for FlashCopy, the report
states No with one of the following explanatory notes:
Note 1 This partition is currently in an active FlashCopy link. See the
table below for details. Use the stop function to break this link.
After the link is broken, you can reissue the FlashCopy backup or
FlashCopy nobackup functions.
Note 2 One or more of the following is true for this partition:
The partition is the boot partition.
The partition has open files.
The partition has a memory-paging file.
You can override these requirements by using the force option.
See the flashcopy backup and flashcopy nobackup functions for
more details.
Note 3 One or more of the following is true for this partition:
The partition is in the blocked state.
The partition is not in the okay or critical state.
The partition is currently synchronizing, rebuilding, or migrating.
Note 4 FlashCopy can support up to four active links only.
Note 5 There is no partition defined on this logical drive.
Use the flashcopy backup function to create a quick snapshot impression of
source partitions on corresponding target partitions. Once the snapshot is
created, the source partitions are ready for immediate use. When the process
completes, each target partition will contain a copy of its source partition's data
that existed at the exact time you issued the flashcopy backup function. A
Array Available
Letter for
FlashCopy
A No (note 1)
A No (note 1)
A Yes
B No (note 5)
B No (note 5)
