XGS2472
FiberTwist Series
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FiberTwist Series and is the answer not in the manual?

Questions and answers

Related Manuals for Genexis FiberTwist Series

Summary of Contents for Genexis FiberTwist Series

  • Page 1 XGS2472 FiberTwist Series Installation Guide...
  • Page 2 LED overview Power Green – system ok Green (blinking) – booting / firmware download – power off Uplink Green – link ok Green (blinking) – link establishing – no link Green – TV signal ok Green (blinking) – insufficient input signal –...
  • Page 3 Button overview Port overview ON/OFF switch Reset Power port LAN ports TV port button Unlock button Remove FiberTwist XGS2472 – press and hold while twisting counterclockwise LED dim button Dim LEDs – press and release repeatedly to dim LEDs Reset button (recessed) ON/OFF switch Reboot –...
  • Page 4 3. Remove the Blind Cover or active device from the baseplate (FTU/Bracket) by pulling Box contents it towards yourself. • Genexis FiberTwist XGS2472 Important: Instructions need to be 4. Store the Blind Cover or active device in a safe place.
  • Page 5 Remove dust cap Twist! 1. Take the FiberTwist XGS2472 out of the box. 1. Place the FiberTwist XGS2472 on the FTU/Bracket as shown in the picture below. 2. The dust cap is connected to the red string located on the rear of the FiberTwist XGS2472. 2.
  • Page 6 1. If required, connect your television / set-top box to the TV port with a coax cable. Hereby, Genexis Netherlands B. V . declares that the radio equipment type FiberTwist XGS2472 is 2. If required, connect your personal devices to the LAN ports via an RJ45 network cable.
  • Page 7 Revision 1.1 - February 2022 - Copyright © 2022 Genexis Netherlands B. V . All rights reserved. Genexis assumes no responsibility for any inaccuracies in this document. Genexis reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
