2.5 Basic Dimensions of Main Components

2.5.1 Dimensions of Sensors

Figure 7: Dimensions of LFS-03SU and LFS-06SU flow sensors
Triclamp
Sensor
Fitting Size
Type
(ASME BPE 2009)
LFS-10SU-Z 1/2"
1"
LFS-15SU-Z
1"
LFS-20SU-Z
Figure 8: Dimensions of LFS-10SU, LFS-15SU and LFS-20SU flow sensors
PL-4509-00, Rev09, DCO# 21-230
Dimensions in [mm]
a b c
Ø 12.7 (= 1/2")
138 80
Ø 25.4 (= 1")
164.8 100
Ø 25.4 (= 1")
231.2 161.2
User Manual for LEVIFLOW
D d e
Ø 25 Ø 9.4 44.4
Ø 50.5 Ø 22.2 79.4
Ø 50.5 Ø 22.2 82.5
®
LFS-SU Flowmeters
www.levitronix.com
f g h
18.6 24 25
23 26 30
28 34 35
L
110
160
160
10
