2.3 Specifications of Converter

2.3.1 Specifications of Single-Channel Converter LFC-1C-PC

Characteristics
Power Supply Voltage / Current / Inrush Current
Ambient Temp / Humidity Range
Enclosure Classification and Material
Interfaces
(see Figure 9 for detailed PIN designation and electrical
specification)
Standard Configuration Parameters
(Available and configurable with RS485/USB converter and
configuration software)
Weight / Dimensions / Mounting
Duration for Activation of Manual and Digital Zeroing
Duration of Zeroing Procedure
Duration of Measurement Ready after Power-On
Warm-Up Time for Full Performance Measurements
Note 1: Other parameters available and described in the Levitronix

2.3.2 Specifications of Multi-Channel Converter LFC-6CIO-PC

Characteristics
Power Supply Voltage / Current / Inrush Current
Ambient Temp / Humidity Range
Enclosure Classification and Material
Interfaces
(see Table 9 for LFC-6C and Table 9/Table 10/Table 11 for
LFC-6CIO for detailed PIN designation and electrical
specification)
1
Configuration Parameters
(Available and configurable with RS485/USB converter and
service software)
Weight / Dimensions / Mounting
Duration for Digital and Manual Zeroing
Duration of Measurement Ready after Power-On
Note 1: Other parameters available and described in the Levitronix
Note: Due to the reduced flow sampling rate per channel, the multi-channel converter LFC-6CIO-PC may be less suitable
for highly dynamic flow measurements in the lower flow range (like for example for flows with sharp pulses caused by roller
pumps).
