2.2 Standard System Configurations

2.2.1 Single Channel System Configuration with LFC-1C-PC

Flow Out
1
Direct connection possible.

2.2.2 Multi-Channel Configuration with LFC-6CIO-PC

1
Figure 5: Standard flowmeter configuration with LFC-6CIO-PC converter
PL-4509-00, Rev09, DCO# 21-230
5a
Flow In
Interconnect Cable
Adaptor/Extension Cable
Various lengths.
Wallmountable connector
for cabinet mounting
Figure 4: Standard flowmeter system configuration
Interconnect Cable
5a
Various lengths.
Direct connection possible.
Adaptor/Extension Cable
Wallmountable connector
for cabinet mounting
User Manual for LEVIFLOW
Single-Channel Converter LFC-1C-PC
Digital
Signal Processor
Piezo Transducers
In-/Output
9
EMI Ferrite
6
5b
RS485 (MODBUS)
- Configuration with PC Software
- Data Logging
- Fieldbus Array of Multiple Sensors
RS485 (MODBUS)
- Configuration with PC Software
- Data Reading
5b Signal/Power Bus Connector
Digital
Signal Processor
DSP
®
LEVIFLOW Converter LFC-6CIO-PC
(6-Channel with I/O Signals)
Address Setting for RS485
®
LFS-SU Flowmeters
www.levitronix.com
DSP
Electrical Interface
Power Supply: 24 VDC
Analog and
Digital Outputs
- 1x Analog Output
- 2x Digital Outputs
- 1x Digital Input
EMI
9
Ferrite
Power Supply: 24 VDC
Analog Outputs:
6 Channels
Digital Outputs:
6 Channels
Digital Inputs:
6 Channels
3
4-Digit Display
Zero Adjustment
2
6
