Levitronix LEVIFLOW LFS-SU User Manual page 5

Pos. Part Name
LFS-03SU-Z
1
LFS-03SU-Z-G25
1a
LFS-03SU-Z-SC1
1
LFS-03SU-Z-SC1-G25
LFS-06SU-Z
1
LFS-06SU-Z-G25
1b
LFS-06SU-Z-SC1
1
LFS-06SU-Z-SC1-G25
LFS-10SU-Z
1
LFS-10SU-Z-G25
1c
LFS-10SU-Z-SC1
1
LFS-10SU-Z-SC1-G25
LFS-15SU-Z
1
LFS-15SU-Z-G25
1d
LFS-15SU-Z-SC1
1
LFS-15SU-Z-SC1-G25
LFS-20SU.1-Z
1
LFS-20SU.1-Z-G25
1e
LFS-20SU-Z-SC1
1
LFS-20SU-Z-SC1-G25
Pos. Part Name
2 LFC-1C-PC
3
LFC-6CIO-PC
(A+B)
4 LFC-1C-PC-SK
Pos. Part Name
LFI-C.1-10
5a LFI-C.1-30
LFI-C.1-60
LFE-C.2-10
5b LFE-C.2-30
LFE-C.2-60
YN-485I-TR, USB to
6 RS485 Adaptor-TR
Isolated
7a Mounting Bracket LMK-1.2
7b Mounting Bracket LMK-2.2
7c Mounting Bracket LMK-3.2
7d Mounting Bracket LMK-4.2
Connector Box
8a
for LFC-6CIO-PC
Termination Box
8b
for LFC-6C
9
LeviFlow Splitting Ferrite
PL-4509-00, Rev09, DCO# 21-230
1% Accuracy
Article #
Flow Range
35 – 800 ml/min
100-30375
100-30399
6 – 800 ml/min
100-30418
100-30419
1.7 – 8 l/min
100-30377
100-30400
0.075 – 8 l/min
100-30394
100-30406
4.7 – 20 l/min
100-30397
100-30405
0.75 – 20 l/min
100-30408
100-30416
10.6 – 50 l/min
100-30412
100-30111
2 – 50 l/min
100-30431
100-30432
18.8 – 80 l/min
100-30483
100-30484
3.2 – 80 l/min
100-30464
100-30465
Table 1: Standard flow sensor configurations
Note 1: Gamma irradiated with dosage > 25 kGy.
Part # Description
Single Channel
100-30374
Converter
6-Channel Converter
with I/O Interfaces
100-30446
(Digital I/O connector 3a and analog
output connector 3b included)
100-91072 Converter Starter Kit
Table 2: LEVIFLOW
Part # Features
190-10307 Cable length: 1 m, PVC
190-10308 Cable length: 3 m, PVC
190-10309 Cable length: 6 m, PVC
190-10310 Cable length: 1 m, PVC
190-10311 Cable length: 3 m, PVC
190-10312 Cable length: 6 m, PVC
Structure/Design
100-30392
Purpose
100-91478 Sensor compatibility
100-91479
100-91480
100-91481
Material / Sensor Fixation
100-30447 COMBICON connector
100-30317 --
100-30353 EMI filtering of DC supply
Table 3: Accessories
User Manual for LEVIFLOW
Fitting Connector
Triclamp 3/8"
Circular Hirose
Triclamp 1/2"
type with IP67.
Triclamp 1"
Triclamp 1"
Interfaces
Analog Output (4 – 20 mA), 2x Digital Output, 1x Digital Input,
RS485 (MODBUS) protocol
Note: EMI ferrite (9) for flow sensor cable included in converter package.
RS485 (MODBUS) protocol
6 analog outputs (4 – 20 mA), 6 digital inputs, 6 digital outputs
Order Bus Conn. (8a) and Termination Box (8b) as separate article.
Note 1: EMI ferrite (9) for bus/supply connection to be ordered as separate article.
When stacking multiple converters same ferrite is needed on every sensor cable.
Flow converter LFC-1C-PC (A) with Ferrite (B)
AC/DC desktop supply (C) AC mains cables and world adaptor set (D)
sensor cable LFI-C.1-30 (E), converter connection cable LFI-D.1 (F)
RS485 to USB cable YN-485I-TR (G) and configuration software
®
converters
Special Feature / Description
Interconnect cable for connection between sensor and converter.
Extension cable with wall-mountable connector for cabinet mounting.
Delivered with protective dust cap on wall-mountable connector side.
USB connector (A) with termination resistor and cable with connector
pair (B and C) for external RS485 wire connection. Magnetically
isolated. Cable length is 2m. Included is USB space saver cable (D).
Communication over fieldbus of converter with PC
For LFS-03SU and LFS-06SU.
For LFS-10SU.
For LFS-15SU
For LFS-20SU.
Anodized Aluminum / Locking pin concept
For wiring RS485 and supply of stacks of LFC-6CIO-PC converter.
For termination of RS485 bus of LFC-6CIO-PC.
For LFC-6CIO-PC supply needed.
On sensor cables needed in case of stacking multiple converters.
®
LFS-SU Flowmeters
www.levitronix.com
Note
--
Firmware requirements for converters:
LFC-1C-PC -> Rev24 or higher
LFC-6CIO-PC -> Rev07 or higher
(H)..
First Release: 11-Dec-2014
Last Update: 07-Oct-2021
