Procedura Di Avvio - gefran EXP-SFTy Manual

Safe stand-still function

Advertisement

Procedura di avvio

Prima dell'avvio eseguire i seguenti controlli:
Funzione Safety : abilitare e disabilitare sin-
golarmente ogni segnale di ingresso relativo a
"Controller enable" e EXP-SFTy", e controllare
l'operatività.
Quando viene attivato un solo ingresso per
volta, la condizione "Safe stand-still" deve es-
sere raggiunta e la simulazione di un guasto
sull'altro ingresso deve disconnettere il con-
tattore di linea.
Controllare la corretta sequenza dei segnali.
attivare le misure di protezione (per es. inter-
locked guard, ecc..), verificare che l'eventuale
rotazione residua del motore non costituisca
un rischio per la sicurezza.
Nel caso l'eventuale rotazione residua del
motore costituisca un rischio per la sicurezza,
valutare la necessità di inserire un freno mec-
canico .
Controllare i segnali di monitor sulla EXP-
SFTy e sui contatti 80/82 (aVy) o 30/32 (XVy-
EV) della scheda di regolazione del drive.
Simulare la condizione di corto circuito e cir-
cuito aperto del contatto di feedback 80/82
(aVy) o 30/32 (XVy-EV) e circuito aperto sui
morsetti di feedback 1/2 e 5/6 e verificare che
il contattore di linea sia disconnesso.
Se le operazioni sopradescritte vengono esegui-
te in modo corretto il drive può essere messo in
servizio .
A
!
ttenzione
Quando viene riscontrato un errore il drive deve
essere disconnesso dalla rete di alimentazione.
Start-up
Run the following checks before start-up:
Safety function: enable and disable each
"Controller enable" and EXP-SFTy input sig-
nal separately and check that they are fully
operational.
When just one input is enabled at a time, the
"Safe stand-still" condition must be reached
and when a fault is simulated on the other in-
put the line contactor must be disconnected.
Check the correct sequence of the signals.
Enable the protective measures (e.g. inter-
locked guard, etc.), make sure than any resid-
ual motor rotation does not represent a safety
hazard.
Should any residual motor rotation represent
a safety hazard, consider the need to include
a mechanical brake.
Check the monitor signals on the EXP-STFy
and on contacts 80/82 (aVy) or 30/32 (XVy-
EV) of the drive regulation card.
Simulate the short circuit and circuit open
condition on feedback contact 80/82 (aVy) or
30/32 (XVy-EV) and the circuit open condition
on feedback terminals 1/2 and 5/6 and check
that the line contactor is disconnected.
If the procedures described above are performed
correctly the drive can be started.
W
!
Arning
Whenever an error occurs, disconnect the drive
from the power supply.
SFTy card
7
