- Page 1 Replace AGy-L by VDL200 En g lish Fast installations and commissioning manual...
- Page 2 Keep the manual in a safe place and available to engineering and installation personnel during the product functioning period. Gefran S.p.A has the right to modify products, data and dimensions without notice. The data can only be used for the product description and they can not be understood as legally stated properties.
-
Page 3: Table Of Contents
Table of contents Introduction ..............................4 Replace the AGy-L: VDL200 Mechanical Installation ..................5 Dimension and weight for models AGy-L 2040 … 3150 ................5 Dimension and weight for models VDL200 1040 … 2110 ................6 Mechanical installation ............................ 7 Maximum inclination and assembly clearances .................. -
Page 4: Introduction
VDL200 as replacement for the old generation AGy-L. The instructions reported below refers to standard installation controlled in multispeed. For more detailed information included the safety precautions refer to the VDL200 Quick Start Guide available on website www.gefran.com. Replace AGy-L by VDL200 Pag. 4 of 17... -
Page 5: Replace The Agy-L: Vdl200 Mechanical Installation
2 Replace the AGy-L: VDL200 Mechanical Installation 2.1 Dimension and weight for models AGy-L 2040 … 3150 Replace AGy-L by VDL200 Pag. 5 of 17... -
Page 6: Dimension And Weight For Models Vdl200 1040
2.2 Dimension and weight for models VDL200 1040 … 2110 148.1 Dimensions: Width x Height x Depth Weight Sizes (mm) (inches) (kg) (lbs) VDL200-1040-...-4 162 x 343 x 159 6.38 x 13.50 x 6,26 12.3 VDL200-1055-...-4 148.1 Dimensions: Width x Height x Depth Weight Sizes (mm) -
Page 7: Mechanical Installation
3 Mechanical installation ----------------------------------------------------------------------------------------------------------------------------------------------- The Drive must be mounted on a wall that is constructed of heat resistant material. While the Drive is operating, the temperature of the Drive’s cooling fins can rise to a temperature of 158° F (70°C). Le drive doit être monté... -
Page 8: Fastening Positions
3.2 Fastening positions Fissaggio a muro • Wall mounting • Fixation mural • Wandmontagee • Fijación en pared 23.5 (5.53) (0.93) 23.5 (0.93) (5.53) Taglia 1 Taglia 2 Size 1 Size 2 Grandeur 1 Grandeur 2 Größe 1 Größe 2 Tamaño 1 Tamaño 2 (5.53) -
Page 9: Replace The Agy-L: Vdl200 Wiring Connection
4 Replace the AGY-L: VDL200 Wiring Connection 4.1 AGy-L Terminals Description Regulation Board DI 1 DO 1 DI 2 DO 2 DI 3 DI 4 COM-DO DI 5 DI 6 (for HTL encoders only) DO 4 DI 7 DI 8 +24Vdc COM-DI (*) Standard= Freq Sel3 src... -
Page 10: Vdl200 Terminals Description
4.2 VDL200 Terminals Description Door Contactor Brake Contactor Drive ON Digital Input 8X BrakeFbk Digital Input 7X MltSpd S2 Digital Input 6X MltSpd S1 Digital Input 5X MltSpd S0 Digital Input 4X Emergency mode Digital Input 3X StartRevCmd Digital Input 2X StartFwdCmd Digital Input 1X Enable HW... -
Page 11: Wiring Corrispondence Table Agy-L / Vdl200
4.3 Wiring Corrispondence table AGy-L / VDL200 Terminal Terminal Type Function Note AGy-L VDL200 Digital Input Drive Enable T1: 9 Digital Input UP direction command T1: 8 Digital Input DOWN direction command T1: 7 Digital Input Multispeed 0 T1: 4 Digital Input Multispeed 1 T1: 3 Digital Input Multispeed 2... -
Page 12: Vdl200 Power Section Wiring
4.4 VDL200 Power section wiring 4.4.1 VDL200: Power Line – Motor- Breaking Resitor Connection Power Line Connection Motor Connection L1 L2 L3 BR C1 C V W EM L1 L2 L3 BR C1 C V W EM 3ph - 23 0 V / 400 V / 460-480 V 50/60 Hz) -
Page 13: Vdl200 Commissioning
5 VDL200 Commissioning This chapter explaines the corispondence of the parameters in AGy-L and the ones in VDL200. If the parameter in AGy-L are not retrievable anylonger, set directly the VDL200 parameters based on the data available (speed, motor data, encoder etc…). 5.1 Set motor parameters in STARTUP WIZARD menu Copy AGy-L PAR into VDL200 PAR... -
Page 14: Execute Autotuning
5.2 Execute Autotuning Auto t une Auto t une 03 STARTUP WIZARD PAR: 2024 Progress 0% Progress 10% Run autotune still Autotune still Press E to exe c ute Close Enable in p ut Press ESC to abort E=Yes Down=Next Put the lift in “Inspection mode”... -
Page 15: Set The Speeds System (Low, High And Inspection)
5.5 Set the speeds system (low, high and inspection) 5.5.1 Multispeed correspondence table AGy-L / VDL200 AGY-L Multispeed S2 sel / Multispeed S1 sel / Multispeed S0 sel / Multispeed Param Notes Terminal 6 Terminal 7 Terminal 25 Multispeed 0 S.200 Low Speed (as default) Multispeed 1... - Page 16 Save all parameters Connect properly the encoder: 0VE out +VE out Go to 04 DRIVE CONFIG menù and scroll down to select PAR 552 Regulation mode and set to 3. Save parameters again with SAVE button on keypad. Note ! See Quick start guide for the complete parameters list. Replace AGy-L by VDL200 Pag.
-
Page 17: In Case Of Problems Adjust The Following Vdl200 Parameters
6 In case of problems adjust the following VDL200 parameters Problem Cause Action Parameters At Start there is a delay to The Motor starts running when the Increase the Brake release the brake and there brake is not completely released or 11064 Menu (5.3.3) Open Delay is a car shock. - Page 18 Fax +44 (0) 8452 604556 info@sieiareg.de Ph. +91 20 6614 6500 sales@gefran.co.uk Fax +91 20 6614 6501 gefran.india@gefran.in SENSORMATE AG GEFRAN MIDDLE EAST ELEKTRIK VE GEFRAN INC. ELEKTRONIK SAN. VE TIC. LTD. STI Steigweg 8, 8 Lowell Avenue Yesilkoy Mah. Ataturk CH-8355 Aadorf, Switzerland WINCHESTER - MA 01890 Cad.
