EPC-R7200 Bottom I/O
2.5.1.
Bottom Door
Please use tool to unscrew the screw on the bottom door.
2.5.2.
Debug Port
EPC-R7200 provides one Debug Port for development used.
Debug cable P/N: 1700021565-01 4P-1.25 to D-SUB 9P (F) 60cm
